SCHROFF Sliderail Serv. Heavyload 10X Telescopic Slide Rail, 100 kg Load, Full Extension, 1000 mm Closed Length, Steel, Zinc-Plated, Side Mount, 19-Inch Rack 23130125

Heavy equipment in server racks and industrial enclosures demands reliable, smooth access for maintenance and upgrades. The SCHROFF Sliderail Serv. Heavyload 10X telescopic slide rail solves this by providing a robust, full-extension platform that supports up to 100 kg per pair, allowing you to pull out even the heaviest chassis completely for safe servicing without disconnecting cables or removing the unit from the rack.

Who is it for

This slide rail is engineered for IT professionals, system integrators, and industrial engineers who manage high-density server rooms, data centers, or heavy machinery enclosures. It is ideal for mounting servers, UPS systems, network storage arrays, and other rack-mounted equipment that requires frequent access or hot-swap capability. If your application involves 19-inch rack systems and demands a durable, corrosion-resistant sliding mechanism, this product is built to perform.

Main features

• Heavy-duty load capacity: supports up to 100 kg per pair (dynamic load), suitable for large servers and industrial equipment.
• Full extension (100%): extends to 2000 mm, providing complete access to the mounted device for maintenance, upgrades, or cable management.
• Three-section telescopic design with ball bearings: ensures smooth, stable sliding even under heavy loads.
• Integrated locking mechanism: locks securely in the extended position to prevent accidental closure during service.
• Zinc-plated steel construction: offers excellent corrosion resistance and long-term durability in demanding environments.
• Side mount orientation: compatible with standard 19-inch rack systems, with a mounting height of 19.1 mm and width of 45.7 mm.
• RoHS compliant: meets environmental standards for restricted substances.

Specifications

• Brand: SCHROFF
• Model: Sliderail Serv. Heavyload 10X
• MPN: 23130125
• EAN: 4036088132094
• Product type: Telescopic slide rail
• Material: Steel
• Finish: Zinc-plated
• Load capacity (dynamic): 100 kg per pair
• Extension type: Full extension (100%)
• Closed length: 1000 mm
• Extended length: 2000 mm
• Mounting height: 19.1 mm
• Mounting width: 45.7 mm
• Bearing type: Ball bearing
• Number of sections: 3-section
• Locking mechanism: Yes, in extended position
• Mounting orientation: Horizontal
• Mounting type: Side mount
• Rack compatibility: 19-inch rack systems
• Corrosion resistance: Yes (due to zinc plating)
• Compliance: RoHS

Tips

To ensure optimal performance and longevity, install the slide rails on both sides of the equipment using the provided mounting holes, and verify that the rack posts are properly aligned. Periodically check the locking mechanism and clean the ball bearings to maintain smooth operation. For installations in high-vibration environments, consider using additional fastening hardware to secure the rails firmly to the rack.
