SATA Cable DeLOCK 84978 0.3m SATA 7-pin Black Blue

This SATA cable by Delock provides an internal connection between SATA devices such as HDDs, SSDs, controller cards or flash memories. The cable is 0.3 m long, uses SATA III 7-pin connectors on both ends and is available in black and blue. It supports the SATA III specification with data transfer rates up to 6 Gb/s and is backwards compatible with earlier SATA versions at their respective speeds.

Advantages

The cable supports the SATA III standard for high-speed data transfers up to 6 Gb/s and remains backward compatible with previous SATA generations. Both ends feature metal clips on the connectors to ensure a secure, click-in connection. The 0.3 m length is suitable for compact internal routing and both connectors are standard SATA 7-pin for broad device compatibility.

Suitable for

• Connecting internal HDDs and SSDs
• Linking SATA controller cards to storage devices
• Replacing or upgrading internal SATA cables in desktop PCs
• Compact builds where a short 0.3 m cable is required

Key specifications

• Cable type: SATA III
• Cable length: 0.3 m
• Connector 1: SATA 7-pin
• Connector 2: SATA 7-pin
• Data transfer rate: up to 6 Gb/s (SATA III)
• Product colour: Black, Blue

How to use

Power down the computer and disconnect it from the mains before installing the cable. Align the SATA 7-pin connector with the SATA port on the device or motherboard, insert until the metal clip clicks to secure the connection. Repeat for the second end. After installation, reconnect power and power on the system to verify the device is recognised by the operating system.

Recommendations

For optimal performance, use this SATA III cable with devices and controllers that support SATA 6 Gb/s. Avoid excessive bending or kinking of the cable and ensure connectors are firmly seated to maintain a reliable connection.
