SAS 3.0 Cable Upgrade Kit FUJITSU for RX2530 M4 S26361-F1592-L100

The FUJITSU SAS 3.0 Cable Upgrade Kit for RX2530 M4 (S26361-F1592-L100) provides the necessary SAS 12 Gbps cabling to install or replace internal and external serial-attached SCSI links in the Fujitsu RX2530 M4 server. Designed to match the physical and electrical requirements of the server, the kit enables high-speed connections between host controllers and drive backplanes or external JBOD enclosures, supporting stable data transfer and straightforward integration into existing storage configurations.

Advantages

The cable kit supports SAS 3.0 12 Gbps signaling for improved throughput compared with previous generations and is manufactured to Fujitsu quality standards to ensure mechanical fit and connector compatibility with the RX2530 M4. Using purpose-designed cables reduces the risk of connection issues, contributes to consistent link performance, and simplifies maintenance or upgrade tasks by providing the correct cabling length and connector types for the server model.

Suitable for

• Replacing worn or damaged internal SAS links in Fujitsu RX2530 M4 servers
• Installing or upgrading host-to-backplane connections to SAS 3.0 12 Gbps
• Connecting RX2530 M4 to compatible external storage enclosures or JBOD units
• Data center maintenance and server hardware refresh operations

Key specifications

• Interface: SAS 3.0 (12 Gbps)
• Connector types: server/backplane compatible SAS connectors suitable for RX2530 M4
• Cable application: internal and external SAS link connections
• Purpose: replacement/upgrade cabling for storage connectivity
• Manufacturer: FUJITSU

How to use

Power down the server and follow electrostatic discharge (ESD) precautions before handling internal components. Identify the current SAS cable routing between the controller and the drive backplane or external enclosure, disconnect existing cables, and replace them with the supplied SAS 3.0 cables, ensuring connectors are fully seated and locking mechanisms engage where present. For external connections, route cables to avoid sharp bends and secure them to prevent strain. After installation, power on the system and verify link status in firmware or management utilities, confirming that drives and enclosures are detected and operating at the expected link speed.

Recommendations

Use the kit with Fujitsu RX2530 M4 systems and compatible storage enclosures only; avoid excessive cable bending and maintain recommended ambient temperatures to preserve signal integrity. When replacing cables in production environments, schedule maintenance windows and verify backups before performing hardware changes. If you encounter link errors after installation, reseat connectors and check cable routing, then consult system logs or Fujitsu support for further diagnostics.
