ROLINE 19-Inch Network Cabinet Pro 22U, 600x600 mm (WxD), Glass Door, Black

The ROLINE 19-Inch Network Cabinet Pro 22U is a high-quality freestanding rack designed for professional network and server environments. With a robust steel construction and a sleek black finish (RAL 9005), this cabinet offers reliable protection and organization for your 19-inch equipment. The front safety glass door allows easy monitoring of installed devices, while the solid steel rear door ensures security. Adjustable 19-inch mounting rails (front and rear) provide flexible installation options.

Advantages

This network cabinet combines durability, security, and ease of use. The fully assembled delivery saves time and effort. The lockable front and rear doors, along with removable side panels, provide controlled access. The 180-degree door opening angle facilitates comfortable installation and maintenance. With a static load capacity of 800 kg, it can accommodate heavy equipment. Passive ventilation and preparation for fan units ensure adequate cooling.

Suitable for

• Server rooms and data centers
• IT infrastructure for small to medium businesses
• Network equipment such as switches, patch panels, and servers
• Secure housing for critical hardware

Key specifications

• Rack height: 22U (1166 mm)
• Width: 600 mm, Depth: 600 mm
• Front door: Safety glass, lockable
• Rear door: Solid steel, lockable
• Side panels: Removable, lockable
• Material: Steel, black RAL 9005
• Static load capacity: 800 kg
• Cable entry: Top and bottom
• Mounting rails: Adjustable 19-inch (front and rear)
• Protection class: IP20
• Ventilation: Passive, prepared for fan units
• Included accessories: 4 leveling feet, 4 castors, 20 cage nuts, 2 keys
• Assembly: Fully assembled

Recommendations

For optimal performance, ensure proper ventilation and consider adding optional fan units. The cabinet is ideal for network closets or server rooms where space is at a premium. Pair with ROLINE patch panels and cable management accessories for a complete solution.
