Rittal enclosure panel HD 2304.010, steel, silver, single-piece

Rittal HD 2304.010 is a single-piece steel enclosure panel with a silver finish designed for use in control cabinets, instrument housings and industrial enclosures. The panel provides a flat, robust mounting surface to protect and organize electrical and electronic components while maintaining a clean, corrosion-resistant appearance. With a compact packaged weight, it is supplied as one unit ready for installation in compatible housings.

Advantages

The steel construction offers structural strength and mechanical protection for mounted components. The silver finish provides a uniform, corrosion-resistant surface that is easy to clean and maintain. Supplied as a single-piece panel, it simplifies installation and reduces the need for multiple parts. Its flat design supports a wide range of mounting options for controls, terminal blocks and small devices.

Suitable for

Key specifications

How to use

Position the panel inside the enclosure at the intended mounting location and secure it using the appropriate fasteners or support rails recommended for the specific cabinet or housing model. Verify that the panel aligns with pre-existing holes or cutouts for components, and use suitable drilling or punching techniques if additional holes are required. Mount electrical components on the panel following standard wiring and grounding practices to maintain safety and EMI considerations.

Recommendations

When installing, confirm compatibility with the enclosure’s internal dimensions and recommended mounting hardware. Use corrosion-resistant fasteners and ensure reliable grounding between the steel panel and the enclosure frame. For outdoor or harsh-environment installations, consider additional surface protection or location-specific enclosures.
