Rittal CM 4116.500 metal profile/rail, grey, compatible with TS CM SE PC TP, depth 35 mm

Rittal CM 4116.500 is a grey metal profile/rail designed for use inside electrical enclosures and control cabinets. With a depth of 35 mm, this single-piece profile provides a stable support element for mounting modules and accessories. It is compatible with a wide range of enclosure systems and is intended for fastening to tubular door frames at any height, enabling flexible positioning of components and DIN-rail mounted devices.

Advantages

The metal profile offers consistent mechanical strength and dimensional accuracy for reliable mounting of electrical components. Its standard grey finish provides corrosion-resistant protection in typical indoor cabinet environments while matching common enclosure interiors. Supplied individually, the rail allows for targeted replacement or extension without overordering. Compatibility with multiple series reduces the need for different profile types across system installations.

Suitable for

Key specifications

How to use

Measure and mark the desired mounting height on the enclosure door frame, taking into account component dimensions and wiring clearances. Position the metal profile so that its depth and orientation align with the chosen mounting plane, then secure using appropriate fasteners compatible with the door frame material and the profile. Attach DIN-rail accessories, terminal blocks or other modules to the mounted profile according to their manufacturer instructions, ensuring proper electrical clearances and grounding where required.
