REPERO WTE721EX-0019-07 Self-Vulcanizing Tape 19mm x 7m Black

The REPERO WTE721EX-0019-07 is a high-quality self-vulcanizing (self-fusing) tape designed for electrical insulation, moisture sealing, and cable repair. Made from Ethylene Propylene Rubber (EPR), this tape fuses to itself without adhesive, creating a solid, waterproof, and UV-resistant seal. With a width of 19 mm and length of 7 m, it is ideal for high voltage applications up to 69 kV with proper layering.

Advantages

Self-vulcanizing technology ensures a permanent, non-adhesive bond that resists moisture, UV, and extreme temperatures from -40°C to 90°C. High dielectric strength (>20 kV/mm) and elongation >700% provide reliable insulation and flexibility. RoHS compliant and compatible with solid dielectric cable insulation.

Suitable for

• Electrical insulation and splicing of cables
• Moisture sealing of electrical connections
• Repair of cable jackets and insulation
• High voltage applications (up to 69 kV with layering)

Key specifications

• Type: Self-Vulcanizing / Self-Fusing
• Material: Ethylene Propylene Rubber (EPR)
• Width: 19 mm
• Length: 7 m
• Thickness: 0.76 mm (30 mil)
• Dielectric Strength: >20 kV/mm
• Operating Temperature: -40°C to 90°C
• Elongation at Break: >700%
• Tensile Strength: >1.5 MPa
• Adhesive: Non-adhesive (fuses to itself)
• Water Resistance: Excellent
• UV Resistance: Good
• Voltage Rating: Suitable for high voltage insulation (up to 69 kV with proper layering)
• Standards: RoHS Compliant
• Packaging: Individually wrapped roll
• Core Diameter: 38 mm

Recommendations

For optimal performance, apply with a 50% overlap and stretch the tape to 75-100% of its original length. Ensure surfaces are clean and dry before application. Suitable for use on cables up to 69 kV when applied in multiple layers.
