Power Supply Unit MEAN WELL HDR-60-24 60W Stainless Steel

The MEAN WELL HDR-60-24 is a 60W DIN-rail power supply in a compact stainless steel housing with an ultra-slim 17.5 mm (1SU) width. It accepts a wide AC input range of 85–264 V and delivers a stable 24 V output for industrial and commercial control applications. Built-in protections for overvoltage, overload and short circuit and safety certifications such as UL60950-1 and TUV EN61558-2-16 support safe and reliable continuous operation.

Advantages

The stainless steel enclosure provides mechanical durability and corrosion resistance while the 17.5 mm slim footprint saves DIN-rail space in panel installations. Wide input voltage compatibility allows use in varied mains environments. Integrated over-voltage, overload and short-circuit protections reduce the need for external protection devices and the unit’s safety approvals ensure compliance with recognized standards.

Suitable for

• Industrial control cabinets and PLC systems
• Building automation and access control
• Communications and network equipment
• Machine tools and small automation modules

Key specifications

• Output power: 60 W
• Output voltage: 24 V DC
• Input voltage: 85–264 V AC
• Width: 17.5 mm (1SU)
• Protection: overvoltage, overload, short circuit
• Housing: stainless steel
• Approvals: UL60950-1, TUV EN61558-2-16

How to use

Mount the HDR-60-24 on a standard DIN-rail and connect the AC mains to the input terminals following local electrical codes. Connect the 24 V DC output to your load, observing correct polarity. Verify grounding of the stainless steel housing where required. If multiple supplies are used, ensure proper load distribution and avoid exceeding the 60 W rating.

Recommendations

Install the unit in a ventilated control cabinet, keep ambient temperature within manufacturer limits, and use appropriate wiring and fusing on the input side. For critical applications, consider redundant power arrangements and periodic inspection for secure terminal connections.
