Power Adapter MEAN WELL UHP-1000-36 1000 W 36 V

The MEAN WELL UHP-1000-36 is a slim, enclosed AC-DC single-output power supply with active power factor correction (PFC). It delivers a stable 36 V DC output at up to 28 A and a maximum output power of 1000 W. The adapter accepts a wide AC input range of 90–264 V, features remote ON/OFF control and a DC OK status signal, and comes in a compact housing (115 × 240 × 41 mm) compliant with RoHS.

Advantages

The UHP-1000-36 offers high output power in a compact form factor, wide input voltage compatibility for global use, and built-in PFC for improved mains efficiency. Remote ON/OFF and DC OK signaling allow system integration and status monitoring. The enclosed design provides electrical protection and simplifies installation in equipment racks or closed enclosures.

Suitable for

• Industrial control systems and automation equipment
• Communication devices and network equipment
• LED lighting drivers and signage power
• Embedded systems and test benches requiring 36 V DC

Key specifications

• Brand: MEAN WELL
• Model: UHP-1000-36
• Output: 36 V DC, 28 A (1000 W max)
• Input voltage: 90–264 V AC
• Type: Slim single-output enclosed AC-DC power supply with PFC
• Remote control: Remote ON/OFF and DC OK signal
• Dimensions: 115 × 240 × 41 mm
• Compliance: RoHS
• MPN: UHP-1000-36
• EAN: 4021087051811

How to use

Install the power supply in a location that allows adequate ventilation and secure mounting using the provided mounting points. Connect the AC input to a compatible mains source within 90–264 V AC, observe correct polarity and grounding. Connect the 36 V DC output to the load, ensuring the combined load does not exceed 28 A. Use the remote ON/OFF terminals to control output power and monitor the DC OK signal for status feedback in your control system. Follow manufacturer wiring diagrams and safety standards during installation.

Recommendations

Ensure the total connected load remains within the 1000 W rating and provide sufficient cooling. Verify grounding and input voltage compatibility before powering on. For reliable long-term operation, avoid installing the unit in environments with excessive dust, moisture, or temperatures beyond the manufacturer’s specified range.
