Power adapter MEAN WELL RSD-60G-5, 60 W, 5 V, 12 A, desktop/supply, 60×128×25 mm

MEAN WELL RSD-60G-5 is a compact 60 W desktop power adapter that delivers a regulated 5 V DC output at up to 12 A. The unit accepts a wide DC input range and provides high isolation between input and output, meeting industry safety and electromagnetic compatibility requirements. With a small footprint of 60 × 128 × 25 mm and RoHS compliance, this supply is intended for embedded systems, network equipment, industrial controllers and other electronics that require a dependable 5 V/12 A source in constrained spaces.

Advantages

The adapter offers a high-efficiency design in a compact enclosed housing, minimizing heat dissipation while providing stable voltage under variable loads. Wide-range DC input compatibility increases installation flexibility in vehicle, industrial and rail environments. The design includes reinforced isolation between input and output, supporting system safety and reducing risk of interference. RoHS compliance ensures reduced hazardous substances in manufacturing and disposal.

Suitable for

• Embedded systems and single-board computers requiring stable 5 V supply
• Routers, switches and network devices with 12 A current demand
• Industrial controllers and automation modules in compact cabinets
• Railway and transport electronics conforming to EN50155 operating conditions

Key specifications

• Output: 5 V DC, maximum 12 A, total power 60 W
• Input range: 9–36 V DC for flexible DC source compatibility
• Isolation: 4000 V DC input-to-output isolation for increased safety
• Form factor: enclosed desktop/supply with dimensions 60 × 128 × 25 mm
• Standards: designed to meet railway EN50155 environment requirements
• Compliance: RoHS-compliant materials

How to use

Install the adapter in a well-ventilated location and ensure the input DC source matches the 9–36 V DC range. Connect the input and output conductors according to the system wiring diagram, observing correct polarity. Power up the source and verify the output voltage before connecting sensitive loads. Allow adequate clearance around the unit for heat dissipation and avoid mounting near strong heat sources or conductive surfaces that could compromise isolation.

Recommendations

For reliable operation, use the adapter within its rated temperature and load limits; avoid continuous operation at maximum current unless sufficient cooling is provided. When deploying in railway or vehicle applications, follow applicable installation and grounding practices for EN50155-compliant systems. Verify wiring insulation and connectors are rated for the installation environment.
