Power adapter MEAN WELL RSD-60G-12, 60 W, 12 V, 5 A, RoHS, 60×128×25 mm

MEAN WELL RSD-60G-12 is a compact 60 W DC-DC enclosed converter that delivers a regulated 12 V output at up to 5 A from a wide 9–36 V DC input range. Housed in a slim 60 × 128 × 25 mm enclosure, this module is designed for industrial and transport applications where space is limited and reliable low-voltage power is required. It meets railway standard EN50155 and provides reinforced isolation between input and output for enhanced safety.

Advantages

The RSD-60G-12 offers a high power density in a small form factor, enabling installation in confined cabinets and equipment racks. Its wide input range and compliance with EN50155 make it suitable for rail and mobile systems, while RoHS conformity ensures reduced hazardous substances. The 4000 Vdc input-to-output isolation increases system safety and helps prevent interference between circuits.

Suitable for

• Powering LED lighting systems and display modules
• Supplying control units and PLC modules in industrial equipment
• Providing stable 12 V for sensors and measurement devices
• Use in rolling stock and other transportation equipment complying with EN50155

Key specifications

• Output voltage: 12 V DC
• Maximum output current: 5 A
• Maximum output power: 60 W
• Input voltage range: 9–36 V DC
• Isolation voltage (input-output): 4000 V DC
• Compliance: railway standard EN50155
• RoHS compliant
• Enclosed converter format, compact dimensions 60 × 128 × 25 mm

How to use

Connect a suitable 9–36 V DC source to the input terminals according to the polarity markings. Verify that the source can supply sufficient current for the expected load. Connect the 12 V DC output to the target device using appropriately rated wiring and secure terminals. Allow adequate ventilation around the enclosure and follow any mounting orientation guidance from the equipment manufacturer. Perform initial power-up tests with no-load and then with incrementally applied load to confirm stable output and proper operation.

Recommendations

For reliable long-term operation, install the converter in an environment within the specified temperature range, avoid exposure to excessive vibration or moisture, and use proper fusing on the input supply. Ensure wiring and connectors match the current rating and maintain clearances to preserve the 4000 V isolation performance.
