Power adapter MEAN WELL DPAN02C-15 2W 15V 36-75V

The MEAN WELL DPAN02C-15 is a compact DC-DC converter designed for PCB mounting. It accepts an input voltage from 36 to 75 VDC and provides a dual regulated output of ±15 V at up to 0.067 A per rail in a SIP through-hole package. The unit delivers 2 W total output power and is RoHS compliant, suitable for installations where a small footprint and reliable bipolar supply are required.

Advantages

The DPAN02C-15 offers a small PCB-mountable form factor and easy integration via a SIP through-hole package. Its wide input range (36–75 VDC) allows use with various vehicle and industrial voltages. The dual ±15 V outputs provide a bipolar supply for analog and mixed-signal circuits while RoHS compliance ensures environmental safety.

Suitable for

• Powering analog front ends and operational amplifiers requiring ±15 V
• Industrial and vehicular systems with 36–75 VDC rails
• PCB-mounted power conversion in compact electronic assemblies

Key specifications

• Manufacturer: MEAN WELL
• Model / MPN: DPAN02C-15
• Input voltage: 36–75 VDC
• Outputs: Dual ±15 VDC
• Output current: 0.067 A per rail
• Total output power: 2 W
• Package: SIP through-hole (PCB mount)
• Compliance: RoHS

How to use

Mount the DPAN02C-15 on the PCB using the SIP through-hole pins and solder according to standard PCB assembly practices. Apply an input voltage within the 36–75 VDC range to the input pins and verify output voltages at the ±15 V output pins under expected load. Observe polarity and grounding conventions when integrating into your circuit. Allow for adequate spacing and thermal considerations per your board layout to ensure reliable operation.

Recommendations

Use appropriate input filtering and transient protection when connecting to automotive or industrial power sources. Verify that the 0.067 A output per rail meets your load requirements, and include decoupling capacitors near powered ICs to maintain stability.
