Power Adapter MEAN WELL DDR-60G-24

The MEAN WELL DDR-60G-24 is an ultra-slim industrial DIN-rail DC-DC converter providing a single 24V DC output at up to 2.5A from a wide 9–36V DC input range. Rated at 60W, this compact module (52.5 × 54.5 × 90 mm) is designed for space‑constrained control cabinets and complies with RoHS requirements for reduced environmental impact.

Advantages

The DDR-60G-24 offers a high power density in an ultra-slim housing suitable for DIN-rail mounting. It supports a wide input voltage span (9–36V DC), delivers a regulated 24V DC output at up to 2.5A, and meets RoHS standards. Its compact dimensions and industrial design allow easy integration into automation, control and telecom enclosures where space is limited.

Suitable for

• Industrial control cabinets and PLC systems
• Rail-mounted automation equipment
• Telecom and network devices requiring 24V DC
• Battery-backed systems and vehicle electronics with 9–36V input

Key specifications

• Model: MEAN WELL DDR-60G-24 (MPN: DDR-60G-24)
• Input voltage: 9–36V DC
• Output: 24V DC, 2.5A (single output)
• Rated power: 60W
• Dimensions: 52.5 mm (W) × 54.5 mm (D) × 90 mm (H)
• Standards: RoHS compliant
• Packaging: 60 units per pack
• EAN: 4021087050685

How to use

Mount the DDR-60G-24 on a standard DIN rail inside the control cabinet. Connect the DC input source (9–36V DC) to the input terminals observing correct polarity and secure wiring. Connect the 24V DC output to the load, ensuring the total current does not exceed 2.5A. Provide appropriate fusing on the input or output according to system requirements and follow local installation regulations. Allow adequate ventilation around the module in confined enclosures.

Recommendations

For reliable operation, verify input voltage range and current requirements prior to installation, use proper overcurrent protection, and avoid exposing the unit to excessive vibration, moisture, or temperatures outside the manufacturer’s specified limits.
