Power adapter/inverter MEAN WELL UHP-200R-24, 200 W, 24 V output, 90–264 V input

MEAN WELL UHP-200R-24 is a compact AC-DC slim enclosed power adapter and inverter providing a regulated 24 V DC output at up to 8.4 A and a total power of 200 W. With a wide input voltage range of 90–264 V AC and built-in power factor correction (PFC), this unit is designed to deliver reliable DC power for industrial control, communication equipment, and embedded systems. The device features a DC OK signal for system monitoring and comes in a space-saving housing measuring 55 × 194 × 26 mm. RoHS compliance ensures reduced hazardous substances.

Advantages

The UHP-200R-24 offers stable 24 V output under varying mains conditions thanks to its wide input range and PFC design. Its slim enclosed form factor allows installation where space is limited while providing effective thermal management. The DC OK signal enables easy integration with supervisory circuits for status monitoring. Robust design and RoHS compliance make it suitable for long-term use in industrial and communication environments.

Suitable for

• Industrial control panels and automation systems
• Communication equipment and network devices
• Embedded systems and single-board computers
• Laboratory and test setups requiring a 24 V supply

Key specifications

• Output voltage: 24 V DC
• Maximum output current: 8.4 A
• Output power: 200 W
• Input voltage range: 90–264 V AC
• Power factor correction (PFC): integrated
• Signal: DC OK status output for monitoring
• Housing type: slim enclosed power supply
• Dimensions: 55 × 194 × 26 mm
• Compliance: RoHS

How to use

Install the unit in a well-ventilated location, allowing clearance for airflow around the housing. Connect the AC input to a suitable mains source within the specified 90–264 V range, observing correct wiring and protective earthing. Connect the 24 V DC output to the load, accounting for the maximum 8.4 A current limit. Use the DC OK signal to feed a monitoring or alarm input on the host system. Follow standard safety practices: isolate power before wiring, use appropriately rated cables, and ensure polarity is correct at the DC terminals.
