Power adapter/inverter Mean Well SPB09C-15 — Input 36–75 V, Output 15 V, 9 W, RoHS, 24 mm depth

Mean Well SPB09C-15 is a compact DC‑DC regulated converter in an SIP through‑hole package. It accepts a wide input range of 36–75 V DC and provides a single fixed 15 V DC output rated at 0.6 A (9 W). The module is designed for PCB mounting, includes a remote ON/OFF function, and is RoHS compliant with a shallow 24 mm depth and low weight suitable for space‑constrained industrial and embedded systems.

Advantages

The SPB09C-15 offers a wide input voltage range for flexibility in varied DC power environments, a regulated single 15 V output for stable low-power supply needs, and a compact SIP through‑hole form factor for straightforward PCB integration. Its remote ON/OFF control enables system-level power management while RoHS compliance ensures adherence to environmental standards.

Suitable for

• Industrial control and automation modules
• Embedded systems and instrumentation
• Telecommunications equipment with 36–75 V DC rails
• Battery-backed or vehicle power systems requiring step‑down conversion

Key specifications

• Manufacturer: Mean Well (brand: mean well)
• Model / MPN: SPB09C-15
• Input voltage: 36–75 V DC
• Output voltage: 15 V DC
• Output current / power: 0.6 A / 9 W
• Package: SIP through‑hole, PCB mount
• Depth: 24 mm
• RoHS: compliant
• EAN: 4021087051859

How to use

Mount the SIP through‑hole converter on the PCB following the manufacturer’s recommended footprint and observe proper soldering practices for through‑hole components. Connect the DC input within the specified 36–75 V range and route the 15 V output to the target circuit, ensuring the load does not exceed 0.6 A. Use the remote ON/OFF pins to control the module according to system requirements, and provide adequate decoupling and grounding as per standard design guidelines.

Recommendations

Operate the SPB09C-15 within its specified input range and output load to preserve regulation and thermal performance; if the application approaches the maximum current, verify board layout and heat dissipation. Follow Mean Well datasheet terminal and pinout details for correct remote ON/OFF wiring and mounting clearance.
