Power adapter/inverter mean well SPAN02C-05 2 W output 5 V input 36–75 V RoHS

Mean Well SPAN02C-05 is a compact DC-DC converter designed for PCB mounting. It accepts a wide input voltage range of 36–75 V DC and provides a regulated single output of 5 V DC at up to 0.4 A in a SIP through-hole package, delivering 2 W of output power. The module is RoHS compliant and intended for low-power embedded and industrial applications where space-efficient, reliable DC conversion is required.

Advantages

The SPAN02C-05 offers a wide input range that accommodates various 36–75 V sources and a fixed, regulated 5 V output suitable for powering microcontrollers and small electronics. Its SIP through-hole package enables straightforward PCB mounting and mechanical stability. The unit is compact, has a 2 W power rating for low-power loads, and complies with RoHS standards for restricted substances.

Suitable for

• Embedded systems and single-board controllers
• Industrial sensors and remote monitoring modules
• Small electronic devices and low-power peripherals
• Applications requiring PCB-mounted DC-DC conversion from 36–75 V to 5 V

Key specifications

• Manufacturer: Mean Well
• Model (MPN): SPAN02C-05
• Input voltage: 36–75 V DC
• Output voltage: 5 V DC
• Output current: 0.4 A (max)
• Output power: 2 W
• Package: SIP through-hole (PCB mount)
• Compliance: RoHS

How to use

Mount the SPAN02C-05 onto a PCB using the SIP through-hole pins and ensure correct polarity of the input connection. Provide an input source within the specified 36–75 V DC range and verify the output with a multimeter before connecting sensitive loads. For stable operation, place the module away from heat sources and follow standard PCB layout recommendations for power modules, including short traces for input/output and adequate grounding.

Recommendations

Do not exceed the rated input voltage range or output current. Use appropriate input filtering and transient protection when connecting the converter to noisy power lines. Allow sufficient spacing around the module for cooling and avoid covering it with insulating materials.
