Power adapter/inverter MEAN WELL SMU02L-12 2 W, Input 4.5–5.5 V, Output 12 V

MEAN WELL SMU02L-12 is an unregulated DC-DC single-output converter in a SIP package that provides 12 VDC at up to 0.167 A (2 W) from a 4.5–5.5 V input. The module features 1500 VDC input-to-output isolation and is designed for compact, low-power applications requiring a 12 V supply derived from a ~5 V source. The product is RoHS-compliant and intended for use in small electronics and embedded systems where space and efficiency are important.

Advantages

The converter delivers a stable 12 V output at low current draw while offering high I/O isolation of 1500 VDC in a small SIP package. Its 4.5–5.5 V input range allows direct use with standard 5 V supplies. The compact size and 2 W power rating make it suitable for space-constrained designs and low-power signal-conditioning tasks.

Suitable for

• Small electronics and handheld devices
• Embedded systems and microcontroller peripherals
• Signal conditioning and sensors
• Applications requiring isolation between input and output

Key specifications

• Manufacturer: MEAN WELL
• Model (MPN): SMU02L-12
• Output: 12 VDC, 0.167 A (2 W)
• Input voltage range: 4.5–5.5 VDC
• Isolation: 1500 VDC input-to-output
• Package: SIP
• Compliance: RoHS
• EAN: 4021087033640

How to use

Connect a regulated 4.5–5.5 VDC supply to the input pins following the module pinout and secure the converter in the circuit. Verify correct polarity before powering. Use appropriate decoupling capacitors and follow good grounding practices to minimize noise. Observe the 2 W output power limit and provide adequate thermal conditions; the unit is intended for low-power applications and not for continuous high-load conditions beyond its rating.
