Power adapter/inverter mean well DPB09C-15 — 9 W, 15 V output, 36–75 V input

Mean Well DPB09C-15 is a compact DC-DC regulated converter designed for PCB mounting. It accepts a wide input range of 36–75 Vdc and provides a single fixed 15 V output rated for 9 W. The unit is supplied in a SIP through-hole package with remote ON/OFF control and is suitable for low-power DC conversion in industrial and OEM electronics.

Advantages

The DPB09C-15 offers a wide input voltage window that accommodates varied supply conditions, a compact SIP through-hole form factor for straightforward PCB assembly, and a low weight and depth (24 mm depth, approximately 5 g) that help conserve board space. RoHS compliance and bulk packaging (2000 pcs per pack) simplify integration into distributed power systems and high-volume manufacturing.

Suitable for

• Industrial electronics and control systems
• Distributed power modules and backplane supplies
• OEM assemblies and equipment with limited board space
• Low-power DC conversion applications requiring 15 V output

Key specifications

• Brand: mean well
• Model / MPN: DPB09C-15
• Power: 9 W
• Input voltage range: 36–75 Vdc
• Output: 15 Vdc (fixed)
• Package: SIP through-hole
• Remote ON/OFF: yes
• Depth: 24 mm
• Weight: ~5 g
• Compliance: RoHS
• Packaging: bulk, 2000 pcs per pack

How to use

Mount the DPB09C-15 in a SIP through-hole position on the PCB following the manufacturer’s recommended footprint and polarity. Apply an input voltage within 36–75 Vdc and verify correct wiring of the remote ON/OFF pin according to your control logic. Allow adequate spacing and basic thermal considerations for continuous 9 W operation and verify output voltage under load before final installation.

Recommendations

Use the converter within the specified input range and rated output power. Provide proper PCB footprint, grounding, and clearance for heat dissipation. For high-volume projects, account for bulk packaging (2000 pcs) when planning procurement and storage.
