POE LANG TC-P3S019 16-Port PoE+ Gigabit Managed Switch with 2 SFP Uplink, 250W, Rackmount

The POE LANG TC-P3S019 is a high-performance 16-port PoE+ managed switch designed for professional network installations. With 16 Gigabit PoE+ ports and 2 SFP uplinks, it delivers reliable power and data connectivity for IP cameras, access points, and other PoE devices. Its Layer 2 management features, including VLAN, QoS, and security protocols, provide flexible network control. The fanless design ensures silent operation, making it ideal for office environments.

Advantages

This switch offers a total PoE budget of 250W, supporting IEEE 802.3af/at standards for powering multiple devices simultaneously. The 36 Gbps switching capacity and 26.78 Mpps forwarding rate ensure smooth data flow. With 6KV lightning protection and a robust metal housing, it guarantees durability and reliability in demanding conditions.

Suitable for

• Small to medium business networks
• IP surveillance systems
• Wireless access point deployments
• VoIP phone systems
• Edge network aggregation

Key specifications

• 16 x 10/100/1000Mbps PoE+ ports
• 2 x Gigabit SFP uplink ports
• PoE standard: IEEE 802.3af/at
• Total PoE power budget: 250W
• Switching capacity: 36 Gbps
• Forwarding rate: 26.78 Mpps
• MAC address table: 8K
• Jumbo frame support: up to 9KB
• Management: Layer 2 managed
• VLAN: 802.1Q tag-based
• QoS support: Yes
• Security: ACL, Port Security, DHCP Snooping
• Mounting: Rackmount 1U
• Power supply: Internal AC 100-240V, 50/60Hz
• Operating temperature: 0°C to 45°C
• Lightning protection: 6KV
• Cooling: Fanless
• Buffer memory: 4.1Mbit

Recommendations

For optimal performance, use quality Cat5e or higher cabling. Ensure proper ventilation in the rack to maintain operating temperature. This switch is an excellent choice for expanding your network with PoE capabilities.
