Phoenix Contact Terminal Block Marker Strip White 5 mm 10 Markers per Strip 10 Strips per Pack 100 Total Markers Pre-printed L1 L2 L3 N PE

The Phoenix Contact 1050017:0031 terminal block marker strips are designed for clear and permanent identification of terminal blocks in industrial control systems. Each strip contains 10 pre-printed markers with the legend L1, L2, L3, N, PE repeated, ensuring consistent labeling for power distribution applications. The markers are made of polyamide (PA) with a flammability rating of UL 94 V2, offering reliable performance in demanding environments.

Advantages

These marker strips provide a snap-on mounting system for quick installation without tools. The white color offers high contrast for easy readability, and the markers are resistant to wiping, solvents, and high-pressure cleaning according to DIN EN 61010-1 (VDE 0411-1). With an operating temperature range of -40 °C to 100 °C, they are suitable for a wide variety of industrial conditions.

Suitable for

• CLIPLINE complete system terminal blocks with 5.2 mm pitch
• Power distribution panels requiring L1, L2, L3, N, PE labeling
• Industrial control cabinets and automation systems

Key specifications

• Product Type: Zack Marker Strip
• Marker Width: 5 mm
• Color: White
• Material: Polyamide (PA)
• Flammability Rating: UL 94 V2
• Operating Temperature: -40 °C to 100 °C
• Mounting Type: Snap-on
• Compatibility: CLIPLINE complete system terminal blocks
• Terminal Block Pitch: 5.2 mm
• Number of Markers per Strip: 10
• Number of Strips per Pack: 10
• Total Markers per Pack: 100
• Marking Type: Pre-printed
• Resistance to Wiping: DIN EN 61010-1 (VDE 0411-1)
• Resistance to Solvents: DIN EN 61010-1 (VDE 0411-1)
• Resistance to High-Pressure Cleaning: DIN EN 61010-1 (VDE 0411-1)

Recommendations

For optimal identification, use these marker strips with Phoenix Contact CLIPLINE terminal blocks. Ensure the terminal block pitch matches 5.2 mm for proper snap-on fit.
