Phoenix Contact Terminal Block Marker Strip 5 mm Pitch White 10 Pieces Pre-printed L1 L2 L3 N PE

The Phoenix Contact 0808671:0001 is a high-quality terminal block marker strip designed for clear and durable identification of electrical circuits. This pre-printed marker strip features the standard legend L1, L2, L3, N, PE repeated, making it ideal for labeling power distribution and control systems. With a 5 mm pitch and snap-on mounting, it is compatible with a wide range of terminal blocks. The markers are made from polyamide (PA) with a UL 94 V2 flammability rating, ensuring reliable performance in demanding environments. Each strip contains 10 markers, providing a convenient solution for professional wiring and maintenance.

Advantages

Pre-printed with common phase and neutral markings saves time and reduces errors during installation. The snap-on design allows for quick and secure attachment without tools. White color provides high contrast for easy reading. Halogen-free and RoHS compliant, supporting environmental and safety standards.

Suitable for

• Industrial control panels
• Building automation systems
• Power distribution boards
• Electrical cabinets and junction boxes

Key specifications

• Product Type: Zack Marker Strip
• Marker Width (Pitch): 5 mm
• Color: White
• Legend: L1, L2, L3, N, PE (repeated)
• Number of Markers per Strip: 10
• Material: Polyamide (PA)
• Mounting Type: Snap-on
• Operating Temperature Range: -40 °C to 100 °C
• Flammability Rating: UL 94 V2
• Print Direction: Horizontal
• Print Type: Pre-printed
• Resistance to Wiping: According to DIN EN 61010-1
• Resistance to Solvents: According to DIN EN 61010-1
• Resistance to High-Pressure Cleaning: According to DIN EN 61010-1
• RoHS Compliant: Yes
• Halogen-free: Yes

Recommendations

For optimal results, use with Phoenix Contact terminal blocks of 5 mm pitch. Ensure the mounting surface is clean and dry before application. Store in a cool, dry place away from direct sunlight.
