Phanteks XT M5 Midi-Tower PC Case, ATX, Mesh Front, Tempered Glass, 3x D-RGB Fans, Black

Supporting up to a 410 mm graphics card and 180 mm CPU cooler, the Phanteks XT M5 is a mid-tower chassis built for high-performance builds. Its mesh front panel and three pre-installed D-RGB fans deliver exceptional airflow out of the box, while the tempered glass side panel showcases your components in style.

Overview

The XT M5 combines a clean, modern aesthetic with practical functionality. The front mesh is optimized for airflow, and the included D-RGB controller allows for vibrant lighting customization, either standalone or synchronized with your motherboard. The interior is spacious and well-organized, with a PSU shroud to keep cables hidden and multiple mounting points for storage and cooling.

What stands out

• High-airflow mesh front panel with fine dust filtration
• Three pre-installed D-RGB fans (2x 140mm front, 1x 120mm rear) with integrated controller
• Tempered glass side panel for a premium look
• Supports E-ATX motherboards (up to 280mm wide) and large graphics cards up to 410mm
• Versatile radiator support: up to 360mm in front and top

Technical details

• Case type: Midi-Tower
• Motherboard support: ATX, Micro-ATX, Mini-ITX, E-ATX (up to 280mm wide)
• Material: Steel, Tempered Glass
• Color: Black
• Expansion slots: 7
• Drive bays: 2x 3.5" (convertible to 2.5"), 2x 2.5" dedicated
• Front I/O: 1x USB 3.0 Type-A, 1x USB 3.0 Type-C, 1x Audio Combo Jack
• Pre-installed fans: 2x 140mm D-RGB (front), 1x 120mm D-RGB (rear)
• Max GPU length: 410 mm
• Max CPU cooler height: 180 mm
• Max PSU length: 230 mm
• Radiator support: Front up to 360mm/280mm, Top up to 360mm/280mm, Rear 120mm
• Dust filters: Front, Top, Bottom
• RGB lighting: Integrated D-RGB controller, Motherboard Sync compatible
• Side panel: Tempered Glass
• PSU shroud: Yes

Our verdict

The Phanteks XT M5 offers an excellent balance of airflow, aesthetics, and compatibility. With its mesh front, three D-RGB fans, and support for high-end hardware, it's a solid foundation for any gaming or workstation build.
