Panel-mount Cinch (RCA) connector DELOCK 91115 gold-plated, white/black housing

DELOCK 91115 is a panel-mount Cinch (RCA) connector with gold-plated contacts and a two-tone white/black housing designed for fixed installation in equipment panels. It provides a stable mating surface for RCA plugs and aims to ensure reliable signal transfer for audio and video connections in AV installations, cabinets, racks and custom enclosures where a durable, clean-looking RCA port is required.

Advantages

The gold-plated contacts reduce contact resistance and improve corrosion resistance compared with unplated metals, supporting consistent signal quality over time. The panel-mount design secures the connector to chassis or panels for a fixed, robust connection point and the contrasting white/black housing offers a neutral appearance that integrates into different installation environments. Mechanical construction facilitates easy mounting and reliable retention of mating plugs.

Suitable for

Key specifications

How to use

Prepare the panel cutout sized to the connector’s mounting dimensions and secure the connector into the opening using the supplied or compatible fastening hardware. Connect the internal wiring to the connector’s terminals according to the device’s grounding and signal layout, taking care to maintain correct polarity for audio channels and video lines. Once mounted and wired, test the connection with standard RCA cables and verify audio/video signal continuity and quality.

Recommendations

Use appropriately rated cables and observe correct shielding and grounding practices in AV installations to minimize interference. For long-term performance, avoid excessive mechanical strain on the mating cable and periodically inspect the gold-plated contacts for cleanliness to maintain optimal signal transfer.
