OXT T250DC Mini ZigBee Tuya Relay Module, Potential-Free, AC 230 V / DC 5 V / 12-48 V

OXT T250DC Mini ZigBee Tuya Relay Module, Potential-Free, AC 230 V / DC 5 V / 12-48 V
OXT T250DC Mini ZigBee Tuya Relay Module, Potential-Free, AC 230 V / DC 5 V / 12-48 V
OXT T250DC Mini ZigBee Tuya Relay Module, Potential-Free, AC 230 V / DC 5 V / 12-48 V
OXT T250DC Mini ZigBee Tuya Relay Module, Potential-Free, AC 230 V / DC 5 V / 12-48 V
OXT T250DC Mini ZigBee Tuya Relay Module, Potential-Free, AC 230 V / DC 5 V / 12-48 V
OXT T250DC Mini ZigBee Tuya Relay Module, Potential-Free, AC 230 V / DC 5 V / 12-48 V
R294
The OXT Mini Module Voltage-free Relay is a compact smart relay module for intelligent control of electrical devices in homes, offices, and automation systems. With its voltage-free NO/NC/COM contact, it is suitable for safely controlling gates, heaters, actuators, lighting, computers, or access con... Read More
Stock 48 Code 3739511 Brand OXT Model T250DC Warranty 2 Years

Shipping & Returns

Estimated delivery Friday, October 9
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The OXT Mini Module Voltage-free Relay is a compact smart relay module for intelligent control of electrical devices in homes, offices, and automation systems. With its voltage-free NO/NC/COM contact, it is suitable for safely controlling gates, heaters, actuators, lighting, computers, or access control systems. It supports 230 V AC, 5 V DC, and 12–48 V DC power and integrates via ZigBee 3.0 with the TUYA Smart / Smart Life ecosystem.

Key features

  • Voltage-free NO/NC/COM contact for versatile applications
  • Supports 230 V AC, 5 V DC, and 12–48 V DC power
  • ZigBee 3.0 communication and compatibility with TUYA Smart / Smart Life
  • Operating modes: monostable, bistable, and bistable with button synchronization
  • Compact Mini housing for flush-mounted box installation
  • Maximum load 10 A, LED up to 250 W

Specifications

  • Brand: OXT
  • MPN: T250DC
  • Product type: Smart Relay Module
  • Connectivity technology: ZigBee
  • Power supply: AC 100–240 V, DC 5 V, DC 12–48 V
  • Communication protocol: ZigBee 3.0
  • Applications: TUYA Smart, Smart Life
  • Relay type: voltage-free, dry contact
  • Maximum load current: 10 A
  • Maximum lighting power: LED 250 W
  • Dimensions: 39 × 39 × 20 mm
  • Protection degree: IP20
  • Operating temperature: -10°C to +40°C
Specifications
Brand
OXT
Category
Smart Home Actuators
Connectivity technology
ZigBee
EAN
5906203623754
Model
T250DC
MPN
T250DC
Product type
Smart Relay Module
