Outlet box JUNG 822 NAW Type F, recessed mounting, 75×151×58 mm

JUNG 822 NAW Type F recessed outlet box is designed for flush-mounted electrical installations. With external dimensions of 75 × 151 × 58 mm, the enclosure provides space for switches, sockets and wiring connections while keeping fittings concealed behind the finished wall surface. The box offers standardized mounting points and an internal layout that supports common electrical components used in residential and commercial settings.

Advantages

The recessed design reduces projection from the wall and enables a clean, concealed finish. Constructed to accommodate standard accessory sizes, the box simplifies installation of switches and sockets. Its dimensions provide a compact but usable internal volume for wiring and connections, and the enclosure material resists typical mechanical stresses encountered during installation and maintenance.

Suitable for

Key specifications

How to use

Select an appropriate cavity in the wall and ensure power is isolated before starting work. Position the JUNG 822 NAW Type F box at the required height and mark the cutout. Fix the enclosure into the wall using suitable screws or mounting hardware for the substrate, and run cables into the box through available entry points. Install switches, sockets or connection terminals onto the provided mounting points, make required electrical connections following regulations, and fit cover plates as required to complete the flush finish.

Recommendations

Verify compatibility of the chosen switches and sockets with the box dimensions before installation, and always follow local electrical codes. Use appropriate cable glands or grommets where needed to protect conductors and maintain a secure installation.
