NKT YDYp 3x1.5 mm² 450/750V PVC Power Cable 100m Reel White

The NKT YDYp 3x1.5 mm² 450/750V PVC Power Cable is a high-quality flat cable designed for fixed installations in dry and damp locations. Manufactured by NKT, a leading European cable producer, this cable meets PN-EN 50525-2-31 standards and is suitable for surface-mounted or embedded wiring in residential, commercial, and industrial buildings.

Advantages

This cable features solid copper conductors for reliable electrical performance, PVC insulation and sheath for durability and flame retardancy, and a flat design that saves space and simplifies installation. The 100-meter reel provides ample length for larger projects, reducing the need for joints.

Suitable for

• Fixed wiring in dry and damp rooms
• Surface-mounted or embedded installations
• Power supply for lighting, sockets, and appliances
• Residential, commercial, and light industrial applications

Key specifications

• Cable type: YDYp (PVC insulated, PVC sheathed, flat)
• Number of cores: 3
• Conductor cross-section: 1.5 mm²
• Rated voltage (U0/U): 450/750 V
• Cable length: 100 m
• Packaging: Reel
• Conductor material: Electrolytic copper (solid, Class 1)
• Insulation material: PVC
• Sheath material: PVC
• Core identification: Brown, Blue, Green/Yellow
• Cable shape: Flat
• Approximate outer dimensions: 5.5 x 9.5 mm
• Maximum operating temperature: +70°C
• Minimum installation temperature: -5°C
• Fire performance: Flame retardant (IEC 60332-1-2)
• Standard: PN-EN 50525-2-31
• Sheath colour: White

Recommendations

For optimal performance, ensure the cable is installed by a qualified electrician and protected against mechanical damage. Suitable for use in conduit, trunking, or clipped direct. Always comply with local electrical regulations.
