Neomounts FPMA-W960D Dual monitor/TV mount wall 10-27 inch - full motion

The Neomounts FPMA-W960D is a dual-screen wall mount for TVs and monitors from 10" up to 27" (69 cm) with a maximum weight capacity of 6 kg per screen. It supports VESA hole patterns from 75x75 mm to 100x100 mm and offers wide tilt, swivel and rotation ranges while the black finish provides a discreet appearance for living rooms, bedrooms or home cinema setups.

Advantages

The mount provides three pivot points with tilt (up to 180°), swivel (up to 180°) and full rotation (360°) for flexible viewing angles. Depth is adjustable from 20.7 to 47 cm to position screens closer to or further from the wall. Integrated cable management routes and conceals cables between the mount and the displays. All necessary installation material is included.

Suitable for

• Dual flat screens or monitors up to 27"
• VESA 75x75 mm and 100x100 mm compatible displays
• Living room, bedroom or home cinema installations
• Applications requiring frequent angle adjustments and cable concealment

Key specifications

• Model: Neomounts FPMA-W960D
• Supported screen size: 10"–27" (max 69 cm)
• Maximum weight capacity: 6 kg per screen
• VESA compatibility: 75x75 to 100x100 mm
• Movement: tilt 0–180°, swivel 180°, rotate 360°
• Depth adjustment: 20.7–47 cm
• Colour: Black

How to use

Mount the bracket to a suitable solid wall following the included instructions and use the supplied fixings. Attach each display to the mount using the proper VESA holes (75x75 or 100x100 mm). Adjust the depth, tilt, swivel and rotation to achieve the desired viewing angle, then route the cables through the integrated cable management channel to keep wiring organized and out of sight.

Recommendations

Ensure each screen does not exceed the maximum weight of 6 kg and that the wall structure can support the combined load. If your display uses a non-standard VESA pattern, use Neomounts VESA adapter plates. Periodically check fastenings and cable routing for safety and a tidy appearance.
