Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX

Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
36 mo.
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
R15,547
MSI PRO X870-P WIFI is an ATX motherboard for Socket AM5, designed to support AMD Ryzen™ 7000–9000 Series processors. The board uses the AMD X870 chipset and supports up to 256 GB of DDR5 memory across four DIMM slots. Built for high-throughput systems, it includes PCIe 5.0 for graphics and NVMe, mu... Read More
Stock Out Of StockNo Stock Code 312218 Brand MSI Model PRO X870-P WIFI Warranty 3 Years

Shipping & Returns

MSI PRO X870-P WIFI is an ATX motherboard for Socket AM5, designed to support AMD Ryzen™ 7000–9000 Series processors. The board uses the AMD X870 chipset and supports up to 256 GB of DDR5 memory across four DIMM slots. Built for high-throughput systems, it includes PCIe 5.0 for graphics and NVMe, multiple M.2 and SATA III storage options with RAID 0/1 support, integrated Wi‑Fi 7 and 5 Gb Ethernet, and a silver aesthetic that fits both white and black PC builds.

Advantages

PRO X870-P WIFI features a 14+2+1 digital power design with dual power connectors and 60A Smart Power Stages to sustain high-end AMD processors. The board provides PCIe 5.0 bandwidth for next‑generation GPUs and NVMe drives, USB4 support, and advanced networking with Wi‑Fi 7 and 5G LAN. MSI integration of AI features in MSI Center and BIOS helps simplify tuning and system management for professional workloads.

Suitable for

  • High-performance desktop builds using AMD Ryzen™ 7000–9000 Series CPUs
  • Content creation and professional multitasking with large DDR5 memory capacities
  • Gaming systems requiring PCIe 5.0 GPUs and fast NVMe storage
  • Workstations needing high-speed networking (Wi‑Fi 7, 5 Gb Ethernet)

Key specifications

  • Form factor: ATX
  • Chipset: AMD X870
  • Socket: AM5
  • Memory: DDR5, up to 256 GB, 4 DIMM slots
  • Storage interfaces: M.2 (PCIe 5.0 support), SATA III; RAID 0/1
  • Networking: Wi‑Fi 7 (802.11be), 5 Gb Ethernet
  • Expansion: PCIe 5.0 for graphics and NVMe

How to use

Install the MSI PRO X870-P WIFI into a compatible ATX case and mount an AM5-compatible AMD Ryzen processor following standard CPU and cooler installation procedures. Populate DDR5 memory modules across the DIMM slots according to the motherboard manual for optimal dual-channel operation. Connect storage devices to M.2 slots or SATA III ports and configure RAID if required. Attach power connectors including the supplemental CPU power as specified, then connect peripherals, network (Wi‑Fi or wired), and proceed to configure BIOS or MSI Center for system settings and any AI-assisted tuning.

Recommendations

For stable performance with high-core-count Ryzen processors, use high-quality power supplies and cooling solutions, populate memory in matched DDR5 kit pairs, and keep BIOS/firmware updated. Use the EZ M.2 Shield Frozr II for thermally sensitive NVMe drives and enable appropriate network drivers for Wi‑Fi 7 and 5 Gb LAN functionality.
Key Highlights
  • Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
  • Supports DDR5 Memory, Dual Channel DDR5 8200+ MT/s (OC)
  • Ultra Performance: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 8-layer PCB made by 2oz thickened copper and server-grade level material
  • Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
  • EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Clip II and EZ Antenna
  • Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
  • Ultra Connect: USB4 and 5G LAN with Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
  • Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience
  • AMD Socket AM5 AMD Ryzen™ 7
  • PC ATX AMD X870 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
  • HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 4
  • 5 Gigabit Ethernet Wi-Fi Wi-Fi 7 (802.11be) Bluetooth 5.4
Specifications
ATX Power connector (24-pin)
Yes
Audio output channels
7.1 channels
Bluetooth
Yes
Bluetooth version
5.4
Compatible processor series
AMD Ryzen™ 7
Component for
PC
CPU fan connector
Yes
Depth
304.8 mm
DisplayPorts quantity
2
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
HDMI ports quantity
1
Maximum internal memory
256 GB
Maximum internal memory supported by processor
256 GB
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD X870
Motherboard chipset family
AMD
Motherboard form factor
ATX
mSATA ports quantity
0
Number of HDDs supported
7
Number of M.2 (M) slots
3
Number of memory slots
4
Number of SATA connectors
0
Number of SATA II connectors
0
Number of SATA III connectors
4
Number of storage drives supported
4
On-board graphics card
No
PC health monitoring
CPU, Fan, Temperature, Voltage
PCI Express x16 slots
4
Processor manufacturer
AMD
Processor socket
Socket AM5
Product colour
Black
RAID levels
0, 1
RAID support
Yes
S/PDIF out port
Yes
Supported memory clock speed (max)
8200 MHz
Supported memory clock speeds
4800,5600,8200 MHz
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Total number of SATA connectors
4
USB 2.0 connectors
4
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
VGA (D-Sub) ports quantity
0
Wi-Fi
Yes
Wi-Fi standards
Wi-Fi 7 (802.11be)
Width
243.8 mm
Windows operating systems supported
Windows 11 x64

Leaflet

Open Leaflet

Manual

Open Manual
Price history over the last 6 months
Motherboard MSI PRO X870-P WIFI, AMD X870, Socket AM5, ATX
Current
R15,547
Lowest
R5,793
Highest
R15,547
Change 24H
+R9,685   +165%
Week
+R9,617   +162%
Month
+R9,617   +162%
