Mounting set Televes MSR-4R for 19 inch rack, 4U height, includes screws (MPN: MSR-4R)

Televes MSR-4R mounting set is a metal accessory designed for installation in standard 19" equipment racks with a 4U height. The kit contains the metal mounting parts and matching screws needed to secure rack-mounted modules, converters and compact appliances. Designed for use where a reliable and space-efficient attachment is required in professional or home rack installations.

Advantages

The mounting set provides a precise fit for 19" rack enclosures at 4U height, ensuring stable mechanical support and correct alignment of equipment. Supplied screws are matched to the metal parts to simplify installation and reduce the need to source fasteners separately. The metal construction delivers consistent rigidity and holds mounted devices firmly in position, minimising vibration and maintaining rack organisation.

Suitable for

• Mounting small converters, signal processing modules and network appliances in a 19" rack
• Professional broadcast, AV and networking racks where a 4U mounting space is required
• Home lab or small server racks for compact devices and modules

Key specifications

• Form factor: compatible with standard 19" equipment racks
• Height occupancy: 4U
• Material: metal mounting parts (steel or similar sturdy alloy)
• Includes: mounting rails/brackets and matching screws for fixation
• Finish: corrosion-resistant coating or treated surface for durability
• Compatibility: designed for standard rack hole spacing and thread types

How to use

Position the mounting rails or brackets at the desired 4U location inside the 19" rack, align the rack holes with the bracket holes and fix the brackets using the supplied screws. Place the device or module onto the mounted brackets and secure it with the remaining screws, ensuring even tightening to avoid deformation. Verify alignment and firmness after installation and check that ventilation and cable routing are not obstructed.

Recommendations

Use appropriate personal protective equipment and follow rack manufacturer guidelines when installing. For heavy appliances, use additional support or two-person handling. Confirm thread compatibility with the rack before final tightening and avoid over-torquing the supplied screws to prevent stripping.
