Mounting bracket SBOX FS-1246F 45–65° tilt, load 32 kg, platform 600×400 mm

SBOX FS-1246F is a fixed-angle mounting bracket for screens or equipment compatible with 600×400 mm hole patterns. The bracket provides a stable, angled installation with an adjustable tilt range of 45–65° and a rated load capacity of 32 kg, allowing secure placement on walls or frames in residential and commercial environments.

Advantages

The bracket offers a wide adjustable tilt range to set optimal viewing or operational angles, combined with a platform sized for standard 600×400 mm hole patterns. Constructed for secure mounting, it supports equipment up to 32 kg and reduces the need for custom fabrication. Its straightforward design simplifies installation and provides consistent, reliable positioning for displays and devices.

Suitable for

• Wall mounting of monitors or displays with 600×400 mm mounting patterns
• Fixed angled installations in retail, office, or public spaces
• Mounting equipment such as thin clients, small AV devices, or control panels up to 32 kg
• Situations requiring a stable 45–65° tilt for ergonomic viewing or equipment access

Key specifications

• Compatible hole pattern: 600×400 mm
• Tilt range: 45–65°
• Maximum load capacity: 32 kg
• Platform dimensions: 600×400 mm
• Mount type: fixed angled wall/frame bracket

How to use

Position the platform against the intended wall or frame surface and mark attachment points according to the 600×400 mm pattern. Secure the bracket using appropriate anchors or bolts for the wall material and the load. Adjust the tilt to a suitable angle within the 45–65° range and ensure all fasteners are tightened. Mount the screen or device onto the platform following the manufacturer’s guidance for the specific equipment, verifying that the total weight does not exceed 32 kg.

Recommendations

Verify wall or frame load-bearing capacity and use suitable fasteners for the substrate. For safety, confirm the combined weight of attached equipment and accessories remains under 32 kg and periodically check fastener tightness and bracket condition, especially in high-traffic or vibration-prone locations.
