Mini PC Zotac ZBOX-MI668-BE i7-1360P 64GB DDR5 SSD Wi-Fi 6

The ZOTAC ZBOX edge MI668 (Barebone) is a 0.64-liter mini PC with an ultra-thin 28 mm chassis designed for space-saving desktop or mounted installations. Powered by Intel Core processors (up to i7-1360P in compatible configurations), DDR5 memory support and integrated Intel Iris Xe graphics, the unit delivers balanced performance for everyday computing, multimedia playback, light creative work, and edge computing tasks. The system includes multiple I/O options and can accommodate up to 2 M.2 SSDs and up to 64 GB DDR5 RAM for higher capacity and responsiveness.

Advantages

The ZBOX edge MI668 combines a compact low-profile design with efficient thermal management and a wide range of connectivity: dual Gigabit Ethernet, Wi-Fi 6 and Bluetooth 5.2, USB 3.x and Thunderbolt 4. Its honeycomb vents and smart fan keep noise and temperatures low while maintaining sustained CPU and integrated GPU performance. The barebone form factor allows straightforward upgrades of M.2 storage and DDR5 memory, giving flexible scalability for different workloads.

Suitable for

• Office productivity and business workstations
• Home multimedia and 4K video playback
• Edge computing, IoT gateway and remote management
• Light content creation and multitasking
• Compact or VESA-mounted deployments in small spaces

Key specifications

• Form factor: 0.64 L mini PC, 28 mm thin chassis
• Processor support: Intel Core (examples include i7-1360P, base 2.2 GHz as in configured models)
• Memory: up to 64 GB DDR5 (two SO-DIMM slots, DDR5 5200 MHz supported)
• Storage: up to 2 × M.2 SSD (PCIe and SATA support depending on configuration)
• Graphics: integrated Intel Iris Xe Graphics
• Networking: Dual Gigabit Ethernet, Wi‑Fi 6 (802.11ax), Bluetooth 5.2
• I/O highlights: USB 3.x, Thunderbolt 4 (up to 40 Gbps), multiple display outputs
• Cooling: wide ventilation, honeycomb vents and Smart Fan

How to use

Install memory modules and M.2 SSDs into the accessible internal slots following the barebone manual, then connect required peripherals and network cables. Mount the unit using the included VESA bracket or place it on a desk. After installing an operating system and drivers, configure network and display settings and install required applications. The active cooling and ventilation are automatic; monitor temperatures and fan behavior using system utilities when performing sustained workloads.

Recommendations

For best results, populate both DDR5 memory slots to enable maximum memory capacity and best multitasking performance, and use NVMe M.2 SSD(s) for lower latency and faster storage throughput. Ensure adequate clearance around honeycomb vents for proper airflow and place the device where Wi‑Fi 6 and Ethernet can provide reliable connectivity for cloud or edge services.
