MikroTik CSS326-24G-2S+RM Managed Layer 2 Switch, 24x Gigabit Ethernet, 2x 10G SFP+, PoE Input, 1U Rackmount, White

The MikroTik CSS326-24G-2S+RM is a managed Layer 2 switch designed for high-performance networking in small to medium-sized businesses. With 24 Gigabit Ethernet ports and 2 SFP+ 10 Gigabit uplinks, it provides ample connectivity for servers, workstations, and network devices. The switch supports PoE input on port 1 (Passive PoE, 10-30V), allowing flexible power options. Its 1U rackmount form factor makes it ideal for data centers and server rooms. Powered by SwOS, it offers advanced management features including VLAN, Link Aggregation, and Port Security.

Advantages

High switching capacity of 48 Gbps ensures smooth data flow. Jumbo frame support up to 10 KB improves performance for large data transfers. The compact and quiet design with no fans makes it suitable for noise-sensitive environments. Easy web-based management simplifies configuration and monitoring.

Suitable for

• Small to medium business networks
• Enterprise edge switching
• Data center top-of-rack deployments
• Surveillance systems requiring PoE input

Key specifications

• 24 x Gigabit Ethernet ports (10/100/1000 Mbps)
• 2 x SFP+ 10 Gigabit ports
• PoE input on Ether1 (Passive PoE, 10-30V)
• Switching capacity: 48 Gbps (full duplex)
• Forwarding rate: 35.7 Mpps
• MAC address table: 16K entries
• Jumbo frame support: up to 10 KB
• Operating system: SwOS
• CPU: QCA8511, 400 MHz
• RAM: 512 KB, Flash: 2 MB
• Power consumption: max 24 W
• DC input: 10-30 V
• Dimensions: 1U rackmount, color: White

Recommendations

For optimal performance, use with MikroTik SFP+ modules and ensure proper ventilation. Ideal for networks requiring reliable Layer 2 switching with 10G uplinks.
