Miboxer LED Controller Waterproof Dual White 2.4G Milight/Miboxer (FUT035S-P)

The Miboxer FUT035S-P is a high-performance, waterproof LED controller designed for dual white (CCT) LED strips. With IP66 rating, it is ideal for both indoor and outdoor applications. It operates via 2.4GHz RF and is compatible with Milight/Miboxer protocols, allowing seamless control with Miboxer remotes or WiFi gateways.

Advantages

This controller offers reliable, interference-free wireless control up to 30 meters. Its robust IP66 waterproof housing ensures durability in harsh environments. The dual-channel output supports warm white and cold white LEDs with 0-100% dimming, enabling perfect color temperature adjustment. Built-in protection against overload, short circuit, and over-temperature ensures safe operation.

Suitable for

• Outdoor LED lighting installations (gardens, patios, facades)
• Indoor ambient lighting with tunable white
• Commercial lighting systems requiring waterproof controllers
• Smart home integration via Miboxer WiFi gateway

Key specifications

• Product Type: LED Controller
• LED Type: Dual White (CCT) LED Strips
• Wireless Technology: 2.4GHz RF
• Wireless Protocol: Mi-Light / Miboxer
• Input Voltage: DC 12V-24V
• Output Current: Max 12A (6A per channel)
• Max Output Power: 144W (12V) / 288W (24V)
• Control Distance: Up to 30 meters
• Waterproof Rating: IP66
• Operating Temperature: -20°C to 60°C
• Number of Channels: 2 (Warm White, Cold White)
• Dimming Range: 0-100%
• Control Compatibility: Miboxer 2.4G remotes, Miboxer WiFi Gateway (WL-Box1/WL-Box2)
• Protection Features: Overload, Short Circuit, Over-temperature
• Housing Material: PC Plastic
• Connection Type: Screw Terminals
• Certifications: CE, RoHS

Recommendations

For best performance, use with Miboxer 2.4G remote or WiFi gateway. Ensure power supply matches voltage and current requirements. Suitable for dry and damp locations.
