Miboxer HR5 5-in-1 RGB-CCT LED Controller DC12-48V 30A 2.4GHz

The Miboxer HR5 is a versatile 5-in-1 LED controller designed for RGB-CCT, RGBW, RGB, dual white, and single color LED strips. It operates on DC 12-48V and supports a total output current of 30A (6A per channel), making it suitable for large-scale lighting installations. With 2.4GHz wireless control, it is compatible with MiBoxer and Milight remotes and gateways, offering smooth 0-100% dimming and color temperature adjustment.

Advantages

This controller provides seamless integration with existing MiBoxer/Milight ecosystems, allowing for flexible control of color, brightness, saturation, and color temperature. Its metal housing ensures durability and heat dissipation, while overload and short circuit protection guarantee safe operation.

Suitable for

• RGB-CCT LED strip installations requiring high current capacity
• Smart home lighting systems using 2.4GHz RF remotes
• Commercial and residential lighting projects needing multi-zone control

Key specifications

• Product Type: LED Controller
• LED Strip Compatibility: 5-in-1 (RGB+CCT, RGBW, RGB, Dual White, Single Color)
• Input Voltage: DC 12V-48V
• Max Output Current: 30A (Total), 6A per Channel
• Max Output Power: 1440W (at 48V)
• Wireless Protocol: 2.4GHz RF
• Control Compatibility: MiBoxer / Milight Ecosystem Remotes & Gateways
• Number of Channels: 5 (R, G, B, Warm White, Cold White)
• Dimming Capability: 0-100% Smooth Dimming
• Control Modes: Color, Brightness, Saturation, Color Temperature Adjustment
• Connection Type: Screw Terminals
• Operating Frequency: 2.400-2.4835GHz
• Control Distance: Up to 30m
• Protection Features: Overload Protection, Short Circuit Protection
• Housing Material: Metal
• Operating Temperature: -20°C to 60°C
• Static Power Consumption: <1W

Recommendations

For optimal performance, use with compatible MiBoxer or Milight 2.4GHz remotes and ensure proper power supply matching the voltage and current requirements. Suitable for indoor use only.
