MIBOXER FUT035S+ LED Controller S-Series 2in1 Dual White/Dim DC12/24V

The MIBOXER FUT035S+ is a versatile 2in1 LED controller designed for S-Series, supporting both dual white (CCT) and single color LED strips. Operating on DC12-24V, it provides smooth 0-100% dimming and is compatible with MiBoxer/MiLight 2.4GHz remote controls, wall panels, and WiFi gateways. Ideal for residential and commercial lighting projects, this controller ensures reliable performance with overload and short circuit protection.

Advantages

Dual functionality for dual white and single color strips; wide input voltage range; high output current up to 12A total; power-off memory function; wireless control distance up to 30 meters; compact ABS housing with screw terminals for easy installation.

Suitable for

• Dual white (CCT) LED strip lighting
• Single color LED strip dimming
• Smart home lighting systems
• Retail, office, and hospitality lighting

Key specifications

• Product Type: LED Controller
• Control Protocol: 2.4GHz RF Wireless
• Input Voltage: DC 12V-24V
• Output Channels: 2 Channels (Dual White / Single Color)
• Max Output Current per Channel: 6A
• Max Total Output Current: 12A
• Max Output Power (12V): 144W
• Max Output Power (24V): 288W
• Dimming Range: 0-100%
• Wireless Control Distance: Up to 30 meters
• Operating Temperature: -20°C to 60°C
• Connection Method: Screw Terminals
• Memory Function: Power-off memory
• Housing Material: ABS Plastic
• Protection Features: Overload Protection, Short Circuit Protection
• Certifications: CE, RoHS

Recommendations

For optimal performance, use with MIBOXER 2.4GHz remote controls or the WL-Box1 WiFi gateway. Ensure power supply voltage matches the LED strip requirements. Not compatible with 0-10V or DALI systems.
