MENNEKES 354 Wall-Mounted Appliance Inlet 16A 2P+E 230V 6h IP44 Blue

Industrial and outdoor electrical installations need a reliable, splash-proof connection point for portable equipment. The MENNEKES 354 wall-mounted appliance inlet provides a secure 16 A, 230 V, 2-pole with earth connection in a compact flange-mount housing, solving the problem of safe power feed-in where protection against moisture is required.

Who is it for

Electricians, panel builders, and maintenance teams working on industrial machinery, commercial kitchens, or outdoor power distribution will appreciate this inlet's straightforward screw-terminal wiring and robust polyamide construction.

Main features

• Rated at 16 A, 230 V (200–250 V), 50/60 Hz for standard single-phase loads.
• 2-pole with earth (2P+E) configuration, earth contact position 6h.
• IP44 splash-proof protection for damp or outdoor environments.
• Flange mounting with 70 x 70 mm dimensions and 56 x 56 mm hole spacing.
• Rear cable entry and screw terminals for secure, maintenance-friendly connections.
• Blue polyamide (PA6) housing with brass contacts for durability.

Specifications

• Connector type: Appliance inlet
• Number of poles: 3-pole (2P+E)
• Rated current: 16 A
• Rated voltage: 230 V (200–250 V)
• Frequency: 50/60 Hz
• Protection degree: IP44
• Earth contact position: 6h
• Connection technology: Screw terminals
• Mounting type: Flange mounting, straight
• Flange dimensions: 70 x 70 mm
• Mounting hole spacing: 56 x 56 mm
• Housing material: Polyamide (PA6)
• Colour: Blue
• Operating temperature range: -25°C to +40°C
• Cable entry: Rear
• Contact material: Brass

Tips

Ensure the mating plug has the same earth contact position (6h) and current rating. Use appropriate cable glands at the rear entry to maintain the IP44 rating.
