MEAN WELL SPBW03G-05 3W DC-DC Converter Module 5V 600mA 9-18V Input DIP24

MEAN WELL SPBW03G-05 3W DC-DC Converter Module 5V 600mA 9-18V Input DIP24
MEAN WELL SPBW03G-05 3W DC-DC Converter Module 5V 600mA 9-18V Input DIP24
R557
This DC-DC converter module delivers a regulated 5V output at 600mA from a 9-18V input, making it a reliable power solution for industrial and embedded systems. Its 2:1 wide input range and 1500VDC isolation ensure stable performance in demanding environments.AdvantagesThe SPBW03G-05 features high e... Read More
Stock 4 Code 3492900 Brand MEAN WELL Model SPBW03G-05 Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

This DC-DC converter module delivers a regulated 5V output at 600mA from a 9-18V input, making it a reliable power solution for industrial and embedded systems. Its 2:1 wide input range and 1500VDC isolation ensure stable performance in demanding environments.

Advantages

The SPBW03G-05 features high efficiency up to 80%, low ripple and noise (50mVp-p), and excellent line/load regulation (±0.5%). It operates over a wide temperature range from -40°C to +85°C with free air convection cooling, and includes short circuit and overload protection for enhanced reliability.

Suitable for

  • Industrial control systems
  • Telecommunication equipment
  • Battery-powered devices
  • Distributed power architectures
  • Test and measurement instruments

Key specifications

  • Input voltage: 9-18 VDC (2:1 range)
  • Output: 5 VDC, 600 mA, 3 W
  • Isolation: 1500 VDC
  • Efficiency: 80% typical
  • Ripple & noise: 50 mVp-p max
  • Operating temperature: -40 to +85 °C
  • Package: DIP24, through-hole mounting
  • MTBF: >1,000,000 hours

Recommendations

For optimal performance, ensure adequate airflow around the module and keep input voltage within the specified range. Use proper PCB layout techniques to minimize noise coupling and maintain isolation integrity.

Specifications
Brand
MEAN WELL
Category
DC-DC Converter Module
Country of origin
Taiwan
Depth
20.3 mm
EAN
4021087040945
Harmonized System (HS) code
85044095
Height
10.2 mm
Input current
0.3 A
Input voltage
9 - 18 VDC
Master (outer) case gross weight
0.5 kg
Master (outer) case height
150 mm
Master (outer) case length
200 mm
Master (outer) case width
150 mm
Model
SPBW03G-05
MPN
SPBW03G-05
Operating temperature (T-T)
-40 - 85 °C
Output current
600 mA
Output voltage
5 VDC
Package depth
35 mm
Package height
25 mm
Package weight
5 g
Package width
15 mm
Power consumption (max)
3 W
Power consumption (typical)
2.4 W
Products per master (outer) case
100
Storage temperature (T-T)
-55 - 105 °C
Weight
4 g
Width
31.8 mm
