MEAN WELL SD-1000L-24 DIN Rail DC-DC Converter 24V 1A 24W

The SD-1000L-24 is a high-efficiency DC-DC converter engineered for industrial automation and control systems, delivering a stable 24 VDC output from a 12 VDC input with exceptional reliability. Its compact DIN rail mounting and wide operating temperature range make it a robust power solution for demanding environments.

Advantages

This converter achieves over 80% efficiency, reducing energy waste and heat generation. It features comprehensive protection against short circuits, overload, and over voltage, ensuring long-term durability. The 1500 VDC input-output isolation provides enhanced safety and noise immunity, while the free air convection cooling eliminates the need for fans, enabling silent and maintenance-free operation.

Suitable for

• Industrial control panels and PLC systems
• Building automation and HVAC controls
• Telecommunication equipment
• Test and measurement instruments
• Security and surveillance systems

Key specifications

• Input voltage: 9 - 18 VDC (nominal 12 VDC)
• Output voltage: 24 VDC
• Output current: 1 A
• Output power: 24 W
• Efficiency: >80%
• Isolation: 1500 VDC
• Mounting: DIN rail
• Operating temperature: -25°C to +70°C
• Protections: short circuit, overload, over voltage
• Certifications: UL 508, CE, RoHS

Recommendations

For optimal performance, ensure proper ventilation around the unit and verify that the input voltage remains within the specified range. Use appropriate wire gauges for screw terminal connections and follow local electrical codes during installation.
