MEAN WELL HRP-600-24 - 648 W Industrial Power Supply, 24 VDC, Active PFC, 90% Efficiency

Where many power supplies falter under continuous load, the HRP-600-24 delivers 648 W with unwavering stability. This enclosed AC/DC converter from MEAN WELL's HRP series is engineered for industrial automation, test equipment, and high-power LED systems that demand tight regulation and long-term reliability. Its active power factor correction and 90% efficiency reduce energy waste and harmonic distortion, while the built-in DC fan with speed control keeps thermals in check even at full output.

Highlights

• 648 W continuous output at 24 VDC with 27 A current capability
• Wide input range: 85–264 VAC or 120–370 VDC
• Active PFC (>0.95) for compliance with EN61000-3-2
• High efficiency up to 90% lowers operating costs
• Built-in DC fan with speed control for quiet, adaptive cooling
• Full protection: short circuit, overload, over voltage, over temperature
• Adjustable output voltage (20–26.4 VDC) and current (50–100%)
• Hold-up time of 16 ms ensures ride-through during brief interruptions

In daily use

Installation is straightforward: the HRP-600-24 features a rugged metal case with screw terminals and a built-in fan that automatically adjusts speed based on load and temperature. The wide operating temperature range of -30 °C to +70 °C allows deployment in harsh environments, from cold storage to factory floors. The unit's 3 kVAC isolation between input and output provides safety and noise immunity, while the low ripple and noise (150 mVp-p) ensures clean power for sensitive electronics. Whether you are powering a CNC machine, a large LED array, or a battery charging system, this supply maintains stable output with minimal drift.

Full specifications

• Output power: 648 W
• Output voltage: 24 VDC (adjustable 20–26.4 VDC)
• Output current: 27 A (adjustable 50–100% via external signal)
• Input voltage: 85–264 VAC / 120–370 VDC
• Input frequency: 47–63 Hz
• Input current: 7.6 A @ 115 VAC, 3.6 A @ 230 VAC
• Efficiency: 90%
• Power factor: >0.95 (active PFC)
• Hold-up time: 16 ms
• Ripple & noise: 150 mVp-p
• Operating temperature: -30 °C to +70 °C
• Protections: short circuit, overload, over voltage, over temperature
• Cooling: built-in DC fan with speed control
• Isolation voltage: 3 kVAC (input to output)
• MTBF: >100,000 hours
• Safety standards: UL 60950-1, TUV EN 60950-1, CB, CE

Final note

The HRP-600-24 is a workhorse for demanding applications where downtime is not an option. Its combination of high power density, comprehensive protections, and compliance with international safety standards makes it a dependable choice for system integrators and OEMs.
