LogiLink 10G Patch Cable Cat.6a S/FTP RJ-45 Male to Male 0.5 m Grey LSZH

The LogiLink CQ6075S is a high-performance 10 Gigabit Ethernet patch cable designed for demanding network environments. With Cat.6a (Class EA) certification, it supports data transfer rates up to 10 Gbps and a bandwidth of 500 MHz, making it ideal for data centers, server rooms, and high-speed LAN applications. The S/FTP shielding (PiMF with overall braid) provides excellent protection against electromagnetic interference, ensuring reliable and stable connections.

Advantages

This cable offers superior performance and durability. The LSZH (Low Smoke Zero Halogen) jacket ensures safety in enclosed spaces by reducing toxic fumes in case of fire. Gold-plated contacts (50µ) guarantee optimal conductivity and corrosion resistance. The stranded 26/7 AWG copper conductors provide flexibility while maintaining signal integrity.

Suitable for

• 10GBASE-T networks
• Data centers and server rooms
• High-speed LAN connections
• Professional AV installations
• Industrial Ethernet applications

Key specifications

• Cable Type: Patch Cable
• Category: Cat.6a (Class EA)
• Shielding: S/FTP (PiMF)
• Data Transfer Rate: Up to 10 Gbps
• Bandwidth: 500 MHz
• Connector 1: RJ-45 Male
• Connector 2: RJ-45 Male
• Cable Length: 0.5 m
• Jacket Material: LSZH
• Colour: Grey
• Conductor Material: Copper
• Conductor Gauge: 26/7 AWG (Stranded)
• Wiring Standard: TIA/EIA 568B
• Contact Plating: Gold-plated (50µ)
• Compliance: RoHS, REACH, ISO/IEC 11801, EN 50173, TIA/EIA 568-C.2

Recommendations

For optimal performance, use this cable with Cat.6a compatible switches and network cards. Ensure proper cable management to avoid kinking or sharp bends. This cable is not recommended for outdoor use.
