LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+

LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+
R6,912
The GTL-2661 series includes high performance Gigabit Ethernet Layer2 switches featuring 26 ports; 24 10/100/1000BASE-T ports, two 10G SFP+ ports, and one 10G expansion slot for a dual port module. The switch is ideal for high performance server aggregations, such as enterprise data centers, where i... Read More
Stock 3 Code 111317 Brand LEVELONE Model GTL-2661 Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
The GTL-2661 series includes high performance Gigabit Ethernet Layer2 switches featuring 26 ports; 24 10/100/1000BASE-T ports, two 10G SFP+ ports, and one 10G expansion slot for a dual port module. The switch is ideal for high performance server aggregations, such as enterprise data centers, where it can connect high end or network attached file servers through fiber ports. It can also deployed as a backbone upgrade, or to provide Gigabit to the desktop for power users. This switch is packed with features and is a cost effective solution that brings continuous availability, enhanced security, and advanced QoS to the network edge, while maintaining simplicity of management.

LevelOne KILBY 26-Port L2 Managed Gigabit Switch, 2 x 10GbE SFP+. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45. MAC address table: 16000 entries, Switching capacity: 88 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE.... Rack mounting

Key Highlights
  • 24 Gigabit Ethernet ports and 2 10-Gigabit SFP+ slots
  • IEEE 802.3ad LACP for auto port aggregation
  • IEEE 802.1d/w/s Spanning Tree Protocol (STP) and port mirroring
  • Provides QoS control based on IP DSCP for advanced traffic prioritization and bandwidth management
  • MLD, Telnet, SNMP V1, V2c & V3, RMON, Web Browser, and TFTP Management
  • Dynamic ARP Inspection (DAI) protects switches against ARP spoofing
  • Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
  • Supports IPv4/IPv6 network operation
  • Managed L2 Web-based management MLD, Telnet, SNMP V1, V2c & V3, RMON, Web Browser, TFTP
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 24 Console port: RJ-45
  • 10G support 10BASE-T, 100BASE-TX, 1000BASE-T
  • MAC address table: 16000 entries Switching capacity: 88 Gbit/s
  • Access Control List (ACL)
  • Rack mounting
  • AC
Specifications
10G support
Yes
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Access Control List (ACL)
Yes
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
BPDU filtering/protection
Yes
Broadcast storm control
Yes
Cable length detection
Yes
Cables included
AC, LAN (RJ-45)
Certification
CE class A, FCC, VCCI, BSMI
Console port
RJ-45
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Country of origin
China
Depth
440 mm
DHCP features
DHCP snooping, DHCP relay, DHCPv6 snooping, DHCP client
DoS attack prevention
Yes
Fanless
Yes
Firmware upgradeable
Yes
Flow control support
Yes
Forwarding rate
65.5 Mpps
Harmonized System (HS) code
85176990
Heat dissipation
68.242 BTU/h
Height
44 mm
Internal memory
32 MB
Jumbo frames
10000
Jumbo frames support
Yes
LED indicators
Activity, Link, Power
Link aggregation
Yes
MAC address table
16000 entries
Management protocols
MLD, Telnet, SNMP V1, V2c & V3, RMON, Web Browser, TFTP
Master (outer) case gross weight
11 kg
Master (outer) case height
435 mm
Master (outer) case length
600 mm
Master (outer) case width
340 mm
Mean time between failures (MTBF)
636219 h
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Number of queues
8
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 50 °C
Package depth
580 mm
Package height
80 mm
Package type
Box
Package weight
3.02 kg
Package width
405 mm
Packet buffer memory
12 MB
Password protection
Yes
Port mirroring
Yes
Power consumption (typical)
20 W
Power over Ethernet (PoE)
No
Power source
AC
Product colour
Black
Products per master (outer) case
4 pc(s)
Quality of Service (QoS) support
Yes
Quick start guide
Yes
Rack mount kit
Yes
Rack mounting
Yes
Rate limiting
Yes
Reset button
Yes
Resource CD
Yes
Safety
UL
SFP+ module slots quantity
2
Spanning tree protocol
Yes
SSH/SSL support
Yes
Static port security
Yes
Static route
Yes
Store-and-forward
Yes
Supported network protocols
IPv4/IPv6
Switch layer
L2
Switch type
Managed
Switching capacity
88 Gbit/s
System event log
Yes
Telnet
Yes
Traffic classification
Yes
Virtual LAN features
Tagged VLAN, MAC address-based VLAN, Port-based VLAN
VLAN support
Yes
Web-based management
Yes
Weight
2.29 kg
Width
220 mm

Leaflet

Open Leaflet

Manual

Open Manual

Manual

Open Manual

Document

Open Document
