LEDVANCE LED Batten Sensor 60cm 8W 830 Warm White PIR Motion Sensor Luminaire

This 60 cm LED batten luminaire with integrated PIR motion sensor delivers 720 lumens of warm white light while consuming only 8 W. The sensor automatically switches the light on when movement is detected and ambient light falls below 10 lx, then switches off after 30 seconds of no movement. This intelligent control reduces energy consumption and provides light only when needed.

Advantages

Automatic switching based on movement and daylight reduces energy consumption. The robust polycarbonate housing with IK03 impact resistance ensures durability, while the long lifespan of 30,000 hours minimizes maintenance. Quick and easy surface mounting is possible with the included accessories.

Suitable for

• Corridors and hallways in residential and commercial buildings
• Stairwells and basements
• Utility rooms and storage areas
• Garages and workshops

Key specifications

• Power consumption: 8 W
• Luminous flux: 720 lm
• Color temperature: 3000 K (warm white)
• Color rendering index: >80
• Beam angle: 120°
• Input voltage: 220-240 V AC, 50/60 Hz
• Lifetime (L70/B50 @ 25°C): 30,000 h
• Switching cycles: 15,000
• Dimmable: No
• Sensor: PIR motion sensor, detection angle 120°, range 2-6 m, hold time 30 s, daylight threshold <10 lx
• IP rating: IP20
• IK rating: IK03
• Housing material: Polycarbonate (PC)
• Operating temperature: -20°C to +40°C
• Energy efficiency class: F
• Mounting: Surface
• Start-up time: <0.5 s

Recommendations

For optimal performance, install at a height of 2-3 meters in areas with ambient temperatures within the specified range.
