Klauke 720AZ Flat Receptacle with Tap, Tab Width 6.3 mm, Tab Thickness 0.8 mm, 180°, Crimp, 0.5-1.5 mm², Uninsulated

The Klauke 720AZ flat receptacle with tap combines a main connection and a branch connection in a single crimp terminal, eliminating the need for separate splices. Its 180° straight orientation and 6.3 mm tab width make it suitable for standard flat connectors, while the 0.8 mm tab thickness ensures a secure fit.

Highlights

• Female flat receptacle with tap for parallel branching
• Tab width: 6.3 mm, tab thickness: 0.8 mm
• Crimp connection for reliable wire termination
• Uninsulated brass body with tin-plated surface
• Wire cross-section range: 0.5 - 1.5 mm² (20 - 16 AWG)

In daily use

This connector is ideal for automotive and electrical applications where a branch circuit is needed without cutting the main wire. The crimp design provides a gas-tight connection, and the tin plating offers corrosion resistance. The straight orientation allows easy access in tight spaces.

Full specifications

• Connector type: Flat receptacle with tap
• Gender: Female
• Tab width: 6.3 mm
• Tab thickness: 0.8 mm
• Connection method: Crimp
• Wire cross-section range: 0.5 - 1.5 mm²
• AWG compatibility: 20 - 16 AWG
• Insulation: Uninsulated
• Material: Brass
• Surface treatment: Tin-plated
• Orientation: Straight (180°)
• Max current rating: 15 A
• Operating temperature range: -40°C to +120°C
• RoHS compliance: Yes
• Branch type: Parallel
• Number of terminals: 2 (Main + Tap)

Final note

Klauke 720AZ offers a compact solution for creating branch connections in wiring harnesses, reducing installation time and improving reliability.
