Keystone module ShiverPeaks S/CONN 08-10072 — angled BNC connector, silver/white finish

The ShiverPeaks S/CONN 08-10072 keystone module is an angled keystone insert with a BNC connector in a silver and white finish, designed for mounting in standard wall plates or panels. It provides a compact, right-angled BNC feedthrough suitable for video and RF signal connections where a low-profile, professional appearance is required. The unit is supplied as a single module and is intended for installations such as CCTV systems, broadcast link points, and laboratory test equipment where reliable coaxial connection and tidy panel integration are needed.

Advantages

The angled BNC design reduces cable strain behind panels and allows connection in confined spaces while maintaining consistent electrical contact. The silver and white finish offers a discreet aesthetic for visible wall-plate installations and resists corrosion in typical indoor environments. As a keystone-format insert, it is compatible with common modular wall plates and panels, enabling straightforward replacement or reconfiguration of connection points without changing the entire plate.

Suitable for (tasks / use cases)

• CCTV camera video feed terminations in wall plates or panels
• Broadcast and studio interface points for composite video or baseband RF
• Test and measurement setups requiring panel-mounted coaxial connectors
• Home media rooms and AV racks where low-profile connections are preferred

Key specifications

• Connector type: BNC, angled (right-angle) orientation
• Form factor: Keystone module for standard modular plates
• Finish: silver and white
• Mounting: panel or wall-plate installation
• Unit supply: single module

How to use

Insert the keystone module into a compatible wall plate or panel cutout until it clicks into place, ensuring the angled BNC faces the desired direction for cable routing. Terminate coaxial cable with a compatible BNC plug and connect to the rear or front face as appropriate for the installation. Verify mechanical retention after insertion and check signal continuity with suitable test equipment before completing the installation. For installations with multiple modules, arrange orientation to minimize cable bends and interference.

Recommendations

Use appropriately rated coaxial cable and BNC terminations for the signal type (video, composite, or RF). Avoid excessive torque on the connector during mating and maintain a gentle bend radius on cables behind the plate to preserve signal integrity and connector life.
