Keystone module RJ45 Cat.6A tool-free, DELOCK 90990, blue

DELOCK Keystone RJ45 module Cat.6A is a tool-free keystone insert designed for Cat.6A network cabling. The blue module provides RJ45 connectivity using an LSA-style connection method that does not require crimping tools. It is compatible with standard keystone openings in wall plates, patch panels and keystone housings and is intended to simplify on-site termination and maintenance of Ethernet networks while maintaining Cat.6A performance characteristics.

Advantages

This keystone module offers tool-free termination, allowing quick insertion and connection of individual conductors without specialized crimp tools. Colour coding and a compact housing make it easy to identify and fit into standard keystone ports. The Cat.6A design supports higher bandwidth and improved crosstalk performance compared with lower categories, making it suitable for demanding Ethernet environments. The module's design supports straightforward replacement and maintenance in structured cabling installations.

Suitable for

Key specifications

How to use

Prepare the Cat.6A cable by stripping the outer sheath to expose the four twisted pairs and arrange the wires according to the chosen wiring standard (T568A or T568B). Insert each conductor into the corresponding slot of the module following the colour marking and press the wires into the LSA-style contacts until they snap into place; this process does not require a crimping tool but may require a simple punch-down action. After termination, trim any excess wire if necessary and snap the module into the keystone opening of a wall plate, patch panel or housing until it locks securely.

Recommendations

For reliable Cat.6A performance, use cable and patch cords rated for Cat.6A and maintain proper pair untwist limits during termination. Ensure consistent wiring standard on both ends of each link. Avoid excessive cable bends and maintain appropriate separation from sources of electromagnetic interference. Verify connections with a suitable network tester after installation to confirm continuity and category-specific performance.
