JOY-IT B-POW Raspberry Pi Power Expansion Board, 6-24V DC Input, 5V 2.5A Output

JOY-IT B-POW Raspberry Pi Power Expansion Board, 6-24V DC Input, 5V 2.5A Output
JOY-IT B-POW Raspberry Pi Power Expansion Board, 6-24V DC Input, 5V 2.5A Output
R324
Deliver a stable 5V/2.5A to your Raspberry Pi from a wide 6–24V DC source with the JOY-IT B-POW power expansion board. The integrated DC/DC step-down converter accepts either a screw terminal or a 5.5×2.1mm barrel jack, making it easy to power your Pi from industrial supplies, battery packs, or exis... Read More
Stock 215 Code 3530027 Brand JOY-IT Model B-POW Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Deliver a stable 5V/2.5A to your Raspberry Pi from a wide 6–24V DC source with the JOY-IT B-POW power expansion board. The integrated DC/DC step-down converter accepts either a screw terminal or a 5.5×2.1mm barrel jack, making it easy to power your Pi from industrial supplies, battery packs, or existing power rails.

Overview

The B-POW is a stacking board that plugs directly onto the Raspberry Pi's 40-pin GPIO header, providing a regulated 5V supply to the Pi and connected peripherals. It is compatible with Raspberry Pi A+, B+, 2B, 3B, 3B+, and 4B. The board includes reverse polarity and overcurrent protection, plus a power LED for status indication.

What stands out

  • Wide 6–24V input range via screw terminal or DC barrel jack
  • High-efficiency DC/DC step-down conversion to 5V
  • Up to 2.5A output current for demanding projects
  • Reverse polarity and overcurrent protection
  • Stacking design preserves GPIO access for other HATs

Technical details

  • Input voltage: 6–24V DC
  • Output voltage: 5V DC
  • Maximum output current: 2.5A
  • Input connectors: screw terminal, 5.5×2.1mm DC barrel jack
  • Output interface: 40-pin GPIO header
  • Protection: reverse polarity, overcurrent
  • Status indicator: power LED
  • Dimensions: 65×56×10 mm
  • Weight: 20 g

Our verdict

A compact, reliable power solution for Raspberry Pi projects that need a flexible input voltage range without sacrificing GPIO access.

Specifications
Brand
JOY-IT
Category
Power Expansion Board
Depth
56
EAN
4250236814728
Height
10
Model
B-POW
MPN
B-POW
Output interface
40-pin GPIO Header
Weight
0.02 kg
Width
65
