Inter-Tech K-17 Active Low Profile CPU Cooler, 92mm PWM, Intel LGA 1150/1151/1155/1156/1200, 45mm Height

The Inter-Tech K-17 is a high-performance active low-profile CPU cooler designed for Intel LGA 1150/1151/1155/1156/1200 sockets. With a total height of only 45 mm, it is ideal for space-constrained systems such as HTPCs, small form factor builds, and 1U/2U server cases. The cooler features a 92 mm PWM fan with hydraulic bearing, delivering efficient cooling with a maximum airflow of 52.5 CFM and noise levels as low as 25 dBA.

Advantages

Ultra-compact design (45 mm height) fits in slim chassis. PWM fan control allows for optimal balance between cooling performance and noise. Aluminum heatsink with copper core ensures excellent heat dissipation for CPUs up to 95W TDP. Hydraulic bearing fan offers long life (40,000 hours MTTF) and quiet operation.

Suitable for

• Intel LGA 1150/1151/1155/1156/1200 socket CPUs
• Small form factor PCs, HTPCs, and home servers
• 1U/2U rackmount systems requiring low-profile cooling
• Upgrades for stock coolers in slim cases

Key specifications

• Cooler Type: Low Profile CPU Cooler (Active)
• Socket Compatibility: Intel LGA 1150, 1151, 1155, 1156, 1200
• Overall Height: 45 mm
• Fan Diameter: 92 mm
• Fan Thickness: 15 mm
• Fan Speed: 800 - 2500 RPM (±10%)
• Max Airflow: 52.5 CFM (89.25 m³/h)
• Max Noise Level: 25.0 dBA
• Bearing Type: Hydraulic Bearing
• Fan Connector: 4-pin PWM
• Max TDP Support: 95 W
• Heatsink Material: Aluminum with Copper Core
• Rated Voltage: 12V DC
• Rated Current: 0.15 A
• MTTF: 40,000 hours

Recommendations

For best performance, ensure proper thermal paste application and adequate case airflow. The K-17 is an excellent choice for building a quiet and compact system without compromising on cooling capability.
