HPE NS204i-u Gen11 Hot Plug Boot Optimized Storage Device

The HPE NS204i-u Gen11 Hot Plug Boot Optimized Storage Device is a high-performance, enterprise-grade boot solution designed for HPE ProLiant Gen11 servers. It integrates two 240 GB M.2 NVMe SSDs in a hardware RAID 1 configuration, delivering reliable and fast operating system boot operations. The hot-plug M.2 module form factor allows for easy installation and maintenance without server downtime.

Advantages

Optimized for boot workloads, this device ensures rapid system startup and enhanced data protection through hardware RAID 1 mirroring. The NVMe PCIe Gen4 interface provides exceptional data transfer speeds, while the hot-plug capability simplifies serviceability. As a genuine HPE component, it guarantees compatibility and reliability in enterprise environments.

Suitable for

• HPE ProLiant Gen11 servers requiring a dedicated boot device
• Enterprise data centers seeking high-availability storage solutions
• Applications needing fast OS boot times and mirrored data protection

Key specifications

• Device Type: Boot Optimized Storage Device
• Storage Type: Solid State Drive (SSD)
• Form Factor: Hot-plug M.2 Module
• Capacity: 480 GB (2x 240 GB M.2 NVMe SSDs)
• Interface: NVMe PCIe Gen4 x2 (per M.2 drive)
• RAID Support: Hardware RAID 1
• Controller: Integrated NVMe Controller
• Compatibility: HPE ProLiant Gen11 Servers
• Hot-Plug Support: Yes
• Number of Drives: 2
• Drive Type: M.2 NVMe SSD
• Application: Operating System Boot Drive
• Data Transfer Rate: Up to 6.4 Gbps (per M.2 drive)
• Endurance: High Endurance (Enterprise Grade)
• Power Consumption: Low (typical for M.2 SSDs)
• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)

Recommendations

For optimal performance, pair this boot device with HPE ProLiant Gen11 servers. Ensure the server has an available M.2 slot supporting NVMe. Regular firmware updates are recommended to maintain compatibility and security.
