HILOOK THC-B157-LMS(2.8mm) 5MP Smart Hybrid Light Turret Camera

The HILOOK THC-B157-LMS is a high-performance 5MP turret camera featuring Smart Hybrid Light technology for 24/7 color imaging. With a 2.8mm fixed lens and 4-in-1 video output (TVI/AHD/CVI/CVBS), it delivers clear surveillance up to 20 meters in full color, even in low-light conditions. Its IP67-rated metal and plastic housing ensures durability for outdoor use.

Advantages

Smart Hybrid Light combines white light and IR for vivid color night vision without compromising on detail. The 5MP resolution provides sharp images, while the turret design offers flexible mounting and a wide field of view. Easy integration with existing analog systems via switchable video output.

Suitable for

• Outdoor perimeter surveillance
• Residential and commercial security
• Areas requiring 24/7 color monitoring
• Retail stores, parking lots, and warehouses

Key specifications

• Image Sensor: 5 MP CMOS
• Max. Resolution: 2560 × 1944
• Lens: 2.8mm fixed focal
• Field of View: 80.1° (H), 57.2° (V), 105.9° (D)
• Video Output: 4-in-1 (TVI/AHD/CVI/CVBS)
• Illumination: Smart Hybrid Light, up to 20m
• Minimum Illumination: 0.001 Lux (F1.0, AGC ON), 0 Lux with white light
• Day/Night: Color (24/7)
• WDR: Digital WDR
• Noise Reduction: 2D DNR
• Frame Rate: 5MP@20fps, 4MP@25/30fps, 1080p@25/30fps
• Power: 12VDC ±25%, max 3.5W
• Ingress Protection: IP67
• Operating Temperature: -40°C to 60°C
• Material: Metal (front cover), Plastic (main body)

Recommendations

For optimal performance, use a compatible 12VDC power supply and ensure proper cable connections. The camera supports up to 20m illumination range; consider additional lighting for larger areas. Ideal for upgrading existing analog systems to high-definition color surveillance.
