Hikvision DS-UPS3000-R(O-STD)/EU 3000 VA 2400 W Online Double Conversion Rackmount UPS (2U)

Unlike many UPS units that use line-interactive or standby topologies, the Hikvision DS-UPS3000-R(O-STD)/EU employs true online double conversion technology. This means the connected load is continuously powered from the inverter, completely isolated from input power fluctuations. With a 3000 VA / 2400 W rating in a 2U rackmount form factor, it is designed for critical IT infrastructure such as servers, storage systems, and network equipment.

Highlights

• True online double conversion with 0 ms transfer time
• 3000 VA / 2400 W capacity
• 2U rackmount chassis
• Pure sine wave output for compatibility with active PFC power supplies
• LCD panel for real-time monitoring
• USB, RS-232, and intelligent slot for SNMP management
• 6 x 12V / 9Ah maintenance-free batteries

In daily use

The DS-UPS3000-R(O-STD)/EU protects against all power anomalies, including surges, sags, and frequency variations. Its configuration flexibility allows input/output voltages of 208, 220, 230, or 240 VAC, making it suitable for a wide range of environments. The 8 x IEC C13 and 1 x IEC C19 outlets provide ample connectivity for servers and networking gear. In addition, the low noise level of <50 dB ensures comfortable operation in office or server room environments.

Full specifications

• UPS Type: Online Double Conversion
• Capacity: 3000 VA / 2400 W
• Form Factor: Rackmount (2U)
• Input Voltage: 208/220/230/240 VAC (configurable)
• Input Voltage Range: 110-300 VAC (full load 176-300 VAC)
• Output Voltage: 208/220/230/240 VAC (configurable)
• Output Frequency: 50/60 Hz (auto-sensing)
• Output Waveform: Pure Sine Wave
• Transfer Time (AC to Battery): 0 ms
• Battery Type: Sealed Lead Acid, Maintenance-Free
• Internal Battery Configuration: 6 x 12V/9Ah
• Recharge Time: 4 hours to 90% capacity
• Output Sockets: 8 x IEC C13, 1 x IEC C19
• Communication Ports: USB, RS-232, Intelligent Slot
• Efficiency (Line Mode): Up to 90%
• Noise Level: <50 dB (at 1 meter)
• Display: LCD Panel

Final note

The Hikvision DS-UPS3000-R(O-STD)/EU is a reliable power protection solution for critical network and server equipment. Its online double-conversion design and comprehensive monitoring options make it a wise investment for any data center or IT installation. Be sure to verify your exact power requirements and connectivity needs before deployment.
